An Investigation of Carbon-Doping-Induced Current Collapse in GaN-on-Si High Electron Mobility Transistors

1
Department of Electrophysics, National Chiao Tung University, 1001 Ta Hsueh Road, Hsinchu 30010, Taiwan
2
Department of Photonics and Institute of Electro-Optical Engineering, National Chiao Tung University, Hsinchu 30010, 1001 Ta Hsueh Road, Hsinchu 30010, Taiwan
3
National Nano Device Laboratories, No. 26, Prosperity Road 1, Hsinchu 30078, Taiwan
4
Epistar, 22 Keya Road, Daya, Central Taiwan Science Park, Taichung 42881, Taiwan
5
Department of Electronics Engineering, National Chiao Tung University, 1001 Ta Hsueh Road, Hsinchu 30010, Taiwan
6
Research Center for Applied Sciences, Academia Sinica, 128 Academia Road, Section 2, Nankang, Taipei 11529, Taiwan
*
Author to whom correspondence should be addressed.
Academic Editor: Farid Medjdoub
Received: 14 March 2016 / Revised: 26 May 2016 / Accepted: 27 May 2016 / Published: 2 June 2016
(This article belongs to the Special Issue Gallium Nitride Electronics)
View Full-Text   |   Download PDF [1672 KB, uploaded 2 June 2016]   |

Abstract

This paper reports the successful fabrication of a GaN-on-Si high electron mobility transistor (HEMT) with a 1702 V breakdown voltage (BV) and low current collapse. The strain and threading dislocation density were well-controlled by 100 pairs of AlN/GaN superlattice buffer layers. Relative to the carbon-doped GaN spacer layer, we grew the AlGaN back barrier layer at a high temperature, resulting in a low carbon-doping concentration. The high-bandgap AlGaN provided an effective barrier for blocking leakage from the channel to substrate, leading to a BV comparable to the ordinary carbon-doped GaN HEMTs. In addition, the AlGaN back barrier showed a low dispersion of transiently pulsed ID under substrate bias, implying that the buffer traps were effectively suppressed. Therefore, we obtained a low-dynamic on-resistance with this AlGaN back barrier. These two approaches of high BV with low current collapse improved the device performance, yielding a device that is reliable in power device applications. View Full-Text
