An FPGA Scalable Software Defined Radio Platform Design for Educational and Research Purposes

1
GTM—Grup de Recerca en Tecnologies Mèdia, La Salle—Universitat Ramon Llull, C/Quatre Camins, 30, 08022 Barcelona, Spain
2
KAL, John Cotton Building, Sunnyside, Edinburgh EH7 5RA, United Kingdom
These authors contributed equally to this work.
*
Author to whom correspondence should be addressed.
Academic Editor: Mostafa Bassiouni
Received: 20 April 2016 / Revised: 23 May 2016 / Accepted: 26 May 2016 / Published: 1 June 2016

Abstract

In a digital modem design, the integration of the Analog to Digital Converters (ADC) and Digital to Analog Converters (DAC) with the core processor is usually a major issue for the designer. In this paper an FPGA scalable Software Defined Radio platform based on a Spartan-6 as a control unit is presented, developed for both educational and research purposes, which can fit the different application requirements in terms of analog front-end performance, processing unit and cost. The resolution and sampling frequency of the analog front-end are its main adjustable parameters. The processing core requirements involve the FPGA and the communication ports. A multidisciplinary working group was required to design a high performance system for both analog front-end and digital processing core in terms of signal integrity and electromagnetic compatibility. The platform has 5 different peripheral ports ranging from 16 kbps to 2.5 Gbps. The communication ports allow our students to develop a high range of applications for both on-site and online courses applying teaching methodology based on learning by doing using a real system to help them to reach other transversal skills.
Keywords: Software Defined Radio (SDR); Field Programable Gate Array (FPGA); programable logic; signal integrity; Electromagnetic Compatibility (EMC); educational platform Software Defined Radio (SDR); Field Programable Gate Array (FPGA); programable logic; signal integrity; Electromagnetic Compatibility (EMC); educational platform
