Improving the Lateral Resolution of Quartz Tuning Fork-Based Sensors in Liquid by Integrating Commercial AFM Tips into the Fiber End

1
SIC-BIO, Bioelectronics and Nanobioengineering Group, Departament d'Electrònica, Universitat de Barcelona, Marti i Franques 1, 08028 Barcelona, Spain
2
Departamento de Física de la Materia Condensada, C-3, Universidad Autónoma de Madrid, Cantoblanco, 28049 Madrid, Spain
Current Address: ETH Zurich, Biosystems Science and Engineering, CH-4057 Basel, Switzerland
*
Author to whom correspondence should be addressed.
Received: 3 November 2014 / Accepted: 5 January 2015 / Published: 14 January 2015
(This article belongs to the Section Physical Sensors)
View Full-Text   |   Download PDF [3073 KB, uploaded 14 January 2015]   |

Abstract

The use of quartz tuning fork sensors as probes for scanning probe microscopy is growing in popularity. Working in shear mode, some methods achieve a lateral resolution comparable with that obtained with standard cantilevered probes, but only in experiments conducted in air or vacuum. Here, we report a method to produce and use commercial AFM tips in electrically driven quartz tuning fork sensors operating in shear mode in a liquid environment. The process is based on attaching a standard AFM tip to the end of a fiber probe which has previously been sharpened. Only the end of the probe is immersed in the buffer solution during imaging. The lateral resolution achieved is about 6 times higher than that of the etched microfiber on its own. View Full-Text
