Length-based separation of DNA remains as relevant today as when gel electrophoresis was introduced almost 100 years ago. While new, long-read genomics technologies have revolutionised accessibility to powerful genomic data, the preparation of samples has not proceeded at the same pace, with sample preparation often constituting a considerable bottleneck, both in time and difficulty. Microfluidics holds great potential for automated, sample-to-answer analysis via the integration of preparatory and analytical steps, but for this to be fully realised, more versatile, powerful and integrable unit operations, such as separation, are essential. We demonstrate the displacement and separation of DNA with a throughput that is one to five orders of magnitude greater than other microfluidic techniques. Using a device with a small footprint (23 mm × 0.5 mm), and with feature sizes in the micrometre range, it is considerably easier to fabricate than parallelized nano-array-based approaches. We show the separation of 48.5 kbp and 166 kbp DNA strands achieving a significantly improved throughput of 760 ng/h, compared to previous work and the separation of low concentrations of 48.5 kbp DNA molecules from a massive background of sub 10 kbp fragments. We show that the extension of DNA molecules at high flow velocities, generally believed to make the length-based separation of long DNA difficult, does not place the ultimate limitation on our method. Instead, we explore the effects of polymer rotations and intermolecular interactions at extremely high DNA concentrations and postulate that these may have both negative and positive influences on the separation depending on the detailed experimental conditions. Full article

As a widely clinical detection method, ultrasonography (US) has been applied to the diagnosis of breast cancer. In this paper, the multi-element synthetic aperture focusing (M-SAF) is applied to the ring array of breast ultrasonography (US) imaging, which addresses the problem of low imaging quality due to the single active element for each emission and the reception in the synthetic aperture focusing. In order to determine the optimal sub-aperture size, the formula is derived for calculating the internal sound pressure of the ring array with a 200 mm diameter, and the sound pressure distribution is analyzed. The ring array with 1024 elements (1024 ring array) is established in COMSOL Multiphysics 5.6, and the optimal sub-aperture size is 16 elements, according to the sound field beam simulation and the directivity research. Based on the existing experimental conditions, the ring array with 256 elements (256 ring array) is simulated and verified by experiments. The simulation has a spatial resolution evaluation in the k-Wave toolbox, and the experiment uses nylon rope and breast model imaging. The results show that if the sub-aperture size has four elements, the imaging quality is the highest. Specifically, the spatial resolution is the best, and the sound pressure amplitude and signal-to-noise ratio (SNR) are maintained at a high level in the reconstructed image. The optimal sub-aperture theory is verified by the two kinds of ring arrays, which also provide a theoretical basis for the application of the multi-element synthetic aperture focusing technology (M-SAF) in ring arrays. Full article

Chemical mechanical polishing (CMP) is a well-known technology that can produce surfaces with outstanding global planarization without subsurface damage. A good CMP process for Silicon Carbide (SiC) requires a balanced interaction between SiC surface oxidation and the oxide layer removal. The oxidants in the CMP slurry control the surface oxidation efficiency, while the polishing mechanical force comes from the abrasive particles in the CMP slurry and the pad asperity, which is attributed to the unique pad structure and diamond conditioning. To date, to obtain a high-quality as-CMP SiC wafer, the material removal rate (MRR) of SiC is only a few micrometers per hour, which leads to significantly high operation costs. In comparison, conventional Si CMP has the MRR of a few micrometers per minute. To increase the MRR, improving the oxidation efficiency of SiC is essential. The higher oxidation efficiency enables the higher mechanical forces, leading to a higher MRR with better surface quality. However, the disparity on the Si-face and C-face surfaces of 4H- or 6H-SiC wafers greatly increases the CMP design complexity. On the other hand, integrating hybrid energies into the CMP system has proven to be an effective approach to enhance oxidation efficiency. In this review paper, the SiC wafering steps and their purposes are discussed. A comparison among the three configurations of SiC CMP currently used in the industry is made. Moreover, recent advances in CMP and hybrid CMP technologies, such as Tribo-CMP, electro-CMP (ECMP), Fenton-ECMP, ultrasonic-ECMP, photocatalytic CMP (PCMP), sulfate-PCMP, gas-PCMP and Fenton-PCMP are reviewed, with emphasis on their oxidation behaviors and polishing performance. Finally, we raise the importance of post-CMP cleaning and make a summary of the various SiC CMP technologies discussed in this work. Full article

Over-molding has been proposed in recent years as an integrated functional flexible circuit board in a plastic part. This method uses the conventional process for film insert technology. Over-molding has attracted significant attention across many industries due to its potential to deliver different electrical functions in a variety of different part geometries, especially in automotive interiors and home appliances. While it has great application potential, manufacturing challenges continue throughout foil fabrication and injection molding. This raises challenges for designers and researchers responsible for maintaining the reliability of such electronic flexible circuits. Therefore, the purpose of this research paper is to improve some of the over-molding process parameters. On 0805 and 1206 over-molded zero-ohm resistors, electrical, mechanical, and failure characterization was performed. Those components were mounted in parallel, perpendicular, and 45° angled arrangements on two different polymer substrates, polyimide (PI) and polyethylene terephthalate (PET) using lead-free solder, low-melt solder, and conductive adhesive paste. Moreover, as an over-molding material, polycarbonate (PC) with medium viscosity was used. The effect of using different mold shapes (corner mold, 2 mm flat mold, and 3 mm flat mold) and injection molding process parameters (injection speeds and melt temperature) was studied. Full article

In this investigation, the compressibility effects are visualized on the flow of non-Newtonian fluid, which obeys the stress–strain relationship of an upper convected Maxwell model in a microchannel. The fundamental laws of momentum and mass conservation are used to formulate the problem. The governing nonlinear partial differential equations are reduced to a set of ordinary differential equations and solved with the help of the regular perturbation method assuming the amplitude ratio (wave amplitude/half width of channel) as a flow parameter. The axial component of velocity and flow rate is computed through numerical integration. Graphical results for the mean velocity perturbation function, net flow and axial velocity have been presented and discussed. It is concluded that the net flow rate and $D_{wall}$ increase in case of the linear Maxwell model, while they decrease in case of the convected Maxwell model. The compressibility parameter shows the opposite results for linear and upper convected Maxwell fluid. Full article

Human epidermal growth factor receptor-3, human epidermal growth factor-receptor-4, and heregulin-α are some of the biomarkers related to gastric cancer currently being used for early detection, personalized treatment, and evaluation of the efficiency of the treatment. Two stochastic sensors based on graphene decorated with TiO₂ and/or Au modified with maltodextrin were proposed for the screening of two types of whole blood and tissue samples for the simultaneous recognition and analysis of the three biomarkers. The sensitivity of the two sensors showed high values, whereas the limits of determination were of fg mL⁻¹ magnitude order. Thus, the proposed screening method can perform the quantitative analysis of both of the biomarkers of interest in whole blood and tissue samples, with recoveries higher than 96.00% and relative standard deviations lower than 1.00%. Full article

The rapid growth in demand for portable and intelligent hardware has caused tremendous pressure on signal sampling, transfer, and storage resources. As an emerging signal acquisition technology, compressed sensing (CS) has promising application prospects in low-cost wireless sensor networks. To achieve reduced energy consumption and maintain a longer acquisition duration for high sample rate electromyogram (EMG) signals, this paper comprehensively analyzes the compressed sensing method using EMG. A fair comparison is carried out on the performances of 52 ordinary wavelet sparse bases and five widely applied reconstruction algorithms at different compression levels. The experimental results show that the db2 wavelet basis can sparse EMG signals so that the compressed EMG signals are reconstructed properly, thanks to its low percentage root mean square distortion (PRD) values at most compression ratios. In addition, the basis pursuit (BP) reconstruction algorithm can provide a more efficient reconstruction process and better reconstruction performance by comparison. The experiment records and comparative analysis screen out the suitable sparse bases and reconstruction algorithms for EMG signals, acting as prior experiments for further practical applications and also a benchmark for future academic research. Full article

A new synthetic strategy has been developed for the facile fabrication of a N-doped porous carbon (NC-800) material via a facile carbonization of functionalized poly(vinylidene fluoride) (PVDF). The prepared NC-800 exhibits good specific capacitance of 205 F/g at 1 A/g and cycle stability (95.2% retention after 5000 cycles at 1 A/g). The adsorption capacity of NC-800 on methylene blue and methyl orange was 780 mg/g and 800 mg/g, respectively. The facile and economical method and good performance (supercapacitor and adsorption) suggest that the NC-800 is a promising material for energy storage and adsorption. Full article

The profile generation is highly complex for roughness measurement using a capacitive sensor because of the small peak-to-peak width of the machined surface and the close proximity of the sensor setting with the machining setup which has the chance of damaging the sensor. Considering these shortcomings, a higher sensor sensing diameter with an appropriate resolution has been selected for a single-shot approach. An automated micro gantry XYZ system is integrated with a capacitive sensor to precisely target, move, and measure the roughness. For investigation, a vertical milled surface with a wide roughness range has been prepared. A Stylus profilometer has been used to measure the roughness (R_a) of the specimens for comparison. An experiment has been conducted on the above system with a 5.6 mm capacitance sensor, and an estimation model using regression has been obtained using sensor data to estimate R_a. In conclusion, the single-shot approach with a 5.6 mm sensing diameter sensor, the proposed micro gantry system, and the estimation model performs better in instantaneous noncontact measurement in the range of 0.3 µm to 2.9 µm roughness estimation. The influence of tilt and waviness has also been discussed using FEA analysis. Full article

Austenitic stainless steels are extensively used in mechanical engineering. The machined surface integrity has an essential influence on the stress corrosion cracking (SCC) performance of stainless steels. In this paper, the effects of multi-pass turning on the SCC susceptibility of AISI 304 austenitic stainless steel were investigated by correlating the SCC crack density to the machining-induced surface characteristics in terms of roughness, micro-hardness, and residual stress. In the multi-pass turning, the surface roughness and residual stress were the least after the double pass turning, and the surface micro-hardness was the maximum after the triple-pass turning. The SCC susceptibility was evaluated after SCC tests in boiling MgCl₂ solution. The results showed that the weakest SCC sensitivity was observed in double-pass turning 304 stainless steel, while the most susceptible SCC was found in triple-pass turning. Compared with the double-pass turning, the increase in SCC sensitivity of triple-pass turning was attributed to the larger roughness, higher micro-hardness and greater residual tensile stresses. Full article

The brain’s learning and adaptation processes heavily rely on the concept of associative memory. One of the most basic associative learning processes is classical conditioning. This work presents a memristive neural network-based associative memory system. The system can emulate Pavlovian conditioning principles including acquisition, extension, generalization, differentiation, and spontaneous recovery that have not been considered in most of the previous counterparts. The proposed circuit can emulate these principles thanks to the resistance-changing characteristics of the memristor. Generalization has been achieved by providing both unconditional and neutral stimuli to the network to reduce the memristance of the memristor. Differentiation has been attained by employing unconditional and conditional stimuli in a training scheme to obtain a certain memristance that causes the network to respond differently to both stimuli. A revival of an exterminated stimuli is also done by increasing the synaptic weight of the system. Compared to previous designs, the proposed memristive circuit can implement all the functions of conditional reflex. Our rigorous simulations demonstrated that the proposed memristive system can condition neutral stimuli, show generalization between similar stimuli, distinguish dissimilarities between the generalized stimuli, and recover faded stimuli. Full article

Monitoring sleep conditions is of importance for sleep quality evaluation and sleep disease diagnosis. Accurate respiration detection provides key information about sleep conditions. Here, we propose a perforated temperature sensor that can be worn below the nasal cavity to monitor breath. The sensing system consists of two perforated temperature sensors, signal conditioning circuits, a transmission module, and a supporting analysis algorithm. The perforated structure effectively enhances the sensitivity of the system and shortens the response time. The sensor’s response time is 0.07 s in air and sensitivity is 1.4‰°C⁻¹. The device can achieve a monitoring respiratory temperature range between normal room temperature and 40 °C. The simple and standard micromachining process ensures low cost and high reproducibility. We achieved the monitoring of different breathing patterns, such as normal breathing, panting, and apnea, which can be applied to sleep breath monitoring and exercise information recording. Full article

The performance of portable or wearable oximeters is affected by improper movement or wear, which causes an error in the blood oxygen concentration calculation. The error comes from external incident stray light or light leakage caused by the improper fit of the sensor to the skin. This study aimed to develop a flexible blood oxygen sensing system with a 3 × 3 array that uses a reflective-type blood oxygen sensing chip to sequentially measure the blood oxygen levels at nine locations through a time division pulse modulation method. Each sensing chip has light transmission and receiving parts. A flip chip package was used to integrate the sensing chip, and a flexible parylene substrate that could fit the curvature of the wrist and locate the array of photo diodes around the radial artery of the wrist was used. By scanning the sensor array in dynamic behavior, the correct light intensity can be extracted to obtain the blood oxygen concentration and prevent errors due to improper fit or sensor movement during exercise. Full article

In this paper, a 650 V 4H-SiC trench Metal-Oxide-Semiconductor Field-Effect Transistor (MOSFET) with a hetero-junction diode (HJD) and double current spreading layers (CSLs) is proposed and studied based on Sentaurus TCAD simulation. The HJD suppresses the turn-on of the parasitic body diode and improves the performance in the third quadrant. CSLs with different doping concentrations help to lower the on-state resistance as well as the gate-drain capacitance. As a result, the on-state resistance is decreased by 47.82% while the breakdown voltage remains the same and the turn-on and turn-off losses of the proposed structure are reduced by 83.39% and 68.18% respectively, compared to the conventional structure. Full article

A novel inhibitable and firing threshold voltage tunable vertical nanowire (NW) single transistor neuron device with core–shell dual-gate (CSDG) was realized and verified by TCAD simulation. The CSDG NW neuron is enclosed by an independently accessed shell gate and core gate to serve an excitatory–inhibitory transition and a firing threshold voltage adjustment, respectively. By utilizing the shell gate, the firing of specific neuron can be inhibited for winner-takes-all learning. It was confirmed that the independently accessed core gate can be used for adjustment of the firing threshold voltage to compensate random conductance variation before the learning and to fix inference error caused by unwanted synapse conductance change after the learning. This threshold voltage tuning can also be utilized for homeostatic function during the learning process. Furthermore, a myelination function which controls the transmission rate was obtained based on the inherent asymmetry between the source and drain in vertical NW structure. Finally, using the CSDG NW neuron device, a letter recognition test was conducted by SPICE simulation for a system-level validation. This multi-functional neuron device can contribute to construct a high-density monolithic SNN hardware combining with the previously developed vertical synapse MOSFET devices. Full article
