Aerospace, Volume 11, Issue 5 (May 2024) – 34 articles

Fuel level gauging in aircraft presents a significant flight mechanics challenge due to the influence of aircraft movements on measurements. Moreover, it constitutes a multidimensional problem where various sensors distributed within the tank must converge to yield a precise and single measurement, independent of the aircraft’s attitude. Furthermore, fuel distribution across multiple tanks of irregular geometries complicates the readings even further. These issues critically impact safety and economy, as gauging errors may compromise flight security and lead to carrying excess weight. In response to these challenges, this research introduces a multi-stage project in aircraft fuel gauging systems, as a continuum of studies, where this first article presents a computational tool designed to simulate aircraft fuel sensor data readings as a function of fuel level, fuel tank geometry, sensor location, and aircraft attitude. Developed in an open-source environment, the tool aims to support the statistical inference required for accurate modeling in which synthetic data generation becomes a crucial component. A discretization procedure accurately maps fuel tank geometries and their mass properties. The tool, then, intersects these geometries with fuel-level planes and calculates each new volume. It integrates descriptive geometry to intersect these fuel planes with representative capacitive level-sensing probes and computes the sensor readings for the simulated flight conditions. The method is validated against geometries with analytical solutions. This process yields detailed fuel measurement responses for each sensor inside the tank, and for different analyzed fuel levels, providing insights into the sensors’ signals’ non-linear behavior at each analyzed aircraft attitude. The non-linear behavior is also influenced by the sensor saturation readings at 0 when above the fuel level and at 1 when submerged. The synthetic fuel sensor readings lay the baseline for a better understanding on how to compute the true fuel level from multiple sensor readings, and ultimately optimizing the amount of used sensors and their placement. The tool’s design offers significant improvements in aircraft fuel gauging accuracy, directly impacting aerostructures and instrumentation, and it is a key aspect of flight safety, fuel management, and navigation in aerospace technology. Full article

Guidance commands of flight vehicles can be regarded as a series of data sets having fixed time intervals; thus, guidance design constitutes a typical sequential decision problem and satisfies the basic conditions for using the deep reinforcement learning (DRL) technique. In this paper, we consider the scenario where the escape flight vehicle (EFV) generates guidance commands based on the DRL technique, while the pursuit flight vehicles (PFVs) derive their guidance commands employing the proportional navigation method. For every PFV, the evasion distance is described as the minimum distance between the EFV and the PFV during the escape-and-pursuit process. For the EFV, the objective of the guidance design entails progressively maximizing the residual velocity, which is described as the EFV’s velocity when the last evasion distance is attained, subject to the constraint imposed by the given evasion distance threshold. In the outlined problem, three dimensionalities of uncertainty emerge: (1) the number of PFVs requiring evasion at each time instant; (2) the precise time instant at which each of the evasion distances can be attained; (3) whether each attained evasion distance exceeds the given threshold or not. To solve the challenging problem, we propose an innovative solution that integrates the recurrent neural network (RNN) with the proximal policy optimization (PPO) algorithm, engineered to generate the guidance commands of the EFV. Initially, the model, trained by the RNN-based PPO algorithm, demonstrates effectiveness in evading a single PFV. Subsequently, the aforementioned model is deployed to evade additional PFVs, thereby systematically augmenting the model’s capabilities. Comprehensive simulation outcomes substantiate that the guidance design method based on the proposed RNN-based PPO algorithm is highly effective. Full article

Tethered balloon systems encounter various complex wind field environments during flight. To investigate the conditions under which the system can operate safely and smoothly, a longitudinal dynamic model for tethered balloon systems is established. The model incorporates a streamlined balloon shape with its aerodynamic center at the body’s center. Steady-state aerodynamic force coefficients are calculated through simulations and fitted to a function based on the angle of attack within a specified range. The complex cable model is simplified using the lumped mass method, considering the influence of branch cables on the main node position. Experimental results from windless oscillation tests on scaled tethered balloon systems are compared with numerical solutions obtained using the dynamic model under the same conditions, validating the feasibility of the model for simulating different wind field scenarios. Finally, the motion characteristics of tethered balloon systems in different wind fields are analyzed. The numerical simulation results show that in a horizontal step wind field, the cable tension and cable inclination angle increase with the wind speed, and the slower the wind field changes, the shorter the time required for system stabilization. Updrafts greatly increase the likelihood of balloon escape, while downdrafts greatly increase the likelihood of the system making contact with the ground. The findings of this study can provide a basis for selecting suitable wind field conditions and issuing risk warnings for tethered balloon systems. Full article

Low-fidelity analytic and computational wave drag prediction methods assume linear aerodynamics and small perturbations to the flow. Hence, these methods are typically accurate for only very slender geometries. The present work assesses the accuracy of these methods relative to high-fidelity Euler, compressible computational-fluid-dynamics solutions for a set of axisymmetric geometries with varying radius-to-length ratios $(R/L)$. Grid-resolution studies are included for all computational results to ensure grid-resolved results. Results show that the low-fidelity analytic and computational methods match the Euler CFD predictions to around a single drag count ( ∼$1.0\times {10}^{-4}$) for geometries with $R/L\le 0.05$ and Mach numbers from 1.1 to 2.0. The difference in predicted wave drag rapidly increases, to over 30 drag counts in some cases, for geometries approaching $R/L\approx 0.1$, indicating that the slender-body assumption of linear supersonic theory is violated for larger radius-to-length ratios. All three methods considered predict that the wave drag coefficient is nearly independent of Mach number for the geometries included in this study. Results of the study can be used to validate other numerical models and estimate the error in low-fidelity analytic and computational methods for predicting wave drag of axisymmetric geometries, depending on radius-to-length ratios. Full article

Recent studies in turbomachinery have shown that the phase of acoustic wave reflection within an intake can have either positive or negative effects on the aeroelastic stability of fan rotor blades. However, the typical flow structures, such as the shock wave, within rotor blade passages with acoustic wave reflection remain unclear. The aim of this research was to address this gap by investigating how these flow structures impact blade aeroelastic stabilities with acoustic wave reflections. The focus of this study was the NASA Rotor 67 blade with an extended intake. Moreover, a bump is incorporated on the shroud at different distances from the fan to reflect acoustic waves of varying phases. Utilizing the energy method, variations in the aerodynamic work density on blade surfaces were calculated under different phases of reflected acoustic waves. Analysis indicates that the spatial position of the shock wave undergoes periodic changes synchronized with the phase of acoustic reflection, marking the first instance of such an observation. This synchronization is identified as the primary factor causing variations in the aeroelastic stability of blades due to acoustic wave reflection, contributing to a deeper understanding of the mechanism behind acoustic flutter. The acoustic–vortex coupling at the blade tip leads to unpredictable variations in unsteady pressures on the blade suction surface, although its effect on blade aeroelastic stabilities is relatively limited compared to that of the shock wave. Full article

Comprehensive rotorcraft simulation codes are the workhorses for designing and simulating helicopters and their rotors under steady and unsteady operating conditions. These codes are also used to predict helicopters’ limits as they approach rotor stall conditions. This paper focuses on the prediction of maximum rotor thrust when hovering (due to stall limits) and the thrust and power characteristics when the collective control angle is further increased. The aerodynamic factors that may significantly affect the results are as follows: steady vs. unsteady aerodynamics, steady vs. dynamic stall, blade tip losses, curvature flow, yaw angle, inflow model, and blade-vortex interaction. The inflow model and tip losses are found to be the most important factors. For real-world applications vortex-based inflow models are considered the best choice, as they reflect the blade circulation distribution within the inflow distribution. Because the focus is on the impact of aerodynamic modeling on rotor stall, the blade design and its flexibility are intentionally not considered. Full article

As an advanced design technology for large wide-body airliners, the three-dimensional (3D) dual-sidestay (DSS) landing gear retraction mechanism can share the ground loads transferred by the landing gear, reducing the load on the wings. However, the addition of a strut system may significantly impact the synchronous locking performance of the landing gear with extremely high sensitivity. To study this impact pattern, both a rigid–flexible-coupling dynamic model of DSS landing gear considering joint clearance and node deviation and a synchronous locking test platform are established in this paper, and the simulation model is validated through the experimental results. Based on the simulation model, this paper conducts a detailed study on the influence of different node deviations and joint clearance on the synchronous locking dynamic characteristics of the DSS landing gear. The results show that, as the node deviation increases, the locking of the lock link gradually lags until one side cannot be fully locked; the structural clearance has a smaller impact on the synchronous locking of the landing gear. The feasible region of parameters satisfying the synchronous locking condition is given, which provides a basis and support for the parameter design of dual-sidestay retraction mechanisms. Full article

This paper discusses various strategies for probabilistic analysis, with a focus on typical engineering applications. The emphasis is on sampling methods and sensitivity analysis. A new sampling method, Latinized particle sampling, is introduced and compared to existing sampling methods. While it can increase the quality of surrogate models, an optimized Latin hypercube sampling is mostly preferable as it shows slightly better results. In sensitivity analysis, the difficulty lies in correlated input variables, which are typical in engineering applications. First, the Sobol indices and the Shapley values are explained using an intuitive example. Then, the modified coefficient of importance is introduced as a new sensitivity measure, which can be used to reliably identify input variables without functional influence. Finally, these results are applied to a turbomachinery test case. In this case, the flow field of a compressor row is investigated, where the blades are subjected to geometric variability. The profile parameters used to describe the geometric variability are correlated. It is shown that the variability of the maximum camber and the thickness of the leading edge have a decisive influence on the variability of the isentropic efficiency. Full article

Computational simulations of three-dimensional flow around a NACA 0018 wing with an aspect ratio of $AR=5$ were carried out by using the Unsteady Reynolds-Averaged Navier–Stokes (URANS) equations with the Shear-Stress Transport turbulence model closure. Simulations were performed to capture aerodynamic stall hysteresis by using the developed pseudo-transient continuation (PTC) method based on a dual-time step approach in CFD OpenFOAM code. The flow was characterized by incompressible Mach number $M=0.12$ and moderate Reynolds number $Re=0.67\times {10}^6$. The results obtained indicate the presence of noticeable aerodynamic hysteresis in the static dependencies of the force and moment coefficients, as well as the manifestation of bi-stable flow separation patterns, accompanied by the development of asymmetry in the stall zone. The URANS simulation results are in good agreement with the experimental data obtained for the NACA 0018 finite-aspect-ratio wing in the low-speed wind tunnel under the same test conditions. A new phenomenological bifurcation model of aerodynamic stall hysteresis under static and dynamic conditions is formulated and is proven to be able to closely match the experimental data. Full article

This article presents an experimental investigation of a passive-adaptive slat concept, an aerodynamic control mechanism aimed at avoiding separation in the inwards region of a horizontal axis wind turbine blade. The passive-adaptive slat is designed to autonomously adjust its position due to the aerodynamic forces acting on it, without the need of any active control system or external power source. The slat opens when the angle of attack increases beyond a certain threshold so that stall is delayed and closes for smaller angles of attack to increase the lift-to-drag ratio of the airfoil. A thorough aerodynamic characterisation of the passive-adaptive slat is performed in the wind tunnel followed by testing it under different sinusoidal inflows generated by a 2D active grid. It is observed that the slat system is able to leverage the advantages of both a clean airfoil and an airfoil with a fixed slat. It has the capability of delaying stalls for higher angles of attack, as well as having higher lift-to-drag ratio for lower angles of attack. It is also observed that, for fluctuating inflow, the passive-adaptive slat is able to achieve similar mean lift values as an airfoil with fixed slat while showing significant reduction in the lift fluctuations. Full article

The flow and morphological characteristics of liquid water on the icing and anti-icing surfaces of aircraft are closely related to the icing characteristics and anti-icing surface temperature distribution. To predict the flow and breakup characteristics of a water film, a 3D model of continuous water film flow and a model of water film breakup into rivulets on an anti-icing surface were constructed based on the icing model, and the corresponding methods for solving the models were developed. Using the NACA0012 airfoil as a simulation object, the changing characteristics of height and velocity for a continuous water film with time and the morphological characteristics of rivulets formed from the breakup of a continuous water film were simulated numerically. The results indicate that, with an increase in inflow velocity, the time required for the water film to completely cover the surface and reach stability decreases. Downstream in the water droplet impact zone, the calculated values of continuous water film height align well with experiments, as well as the stream height at the continuous water film rupture location with the experimental values. With the reasonable contact angle, the calculation error of the stream width is within 10%. Full article

Exploring the Moon and Mars are crucial steps in advancing space exploration. Numerous missions aim to land and research in various lunar locations, some of which possess challenging surfaces with unchanging features. Some of these areas are cataloged as lunar light plains. Their main characteristics are that they are almost featureless and reflect more light than other lunar surfaces. This poses a challenge during navigation and landing. This paper compares traditional feature matching techniques, specifically scale-invariant feature transform and the oriented FAST and rotated BRIEF, and novel machine learning approaches for dense feature matching in challenging, unstructured scenarios, focusing on lunar light plains. Traditional feature detection methods often need help in environments characterized by uniform terrain and unique lighting conditions, where unique, distinguishable features are rare. Our study addresses these challenges and underscores the robustness of machine learning. The methodology involves an experimental analysis using images that mimic lunar-like landscapes, representing these light plains, to generate and compare feature maps derived from traditional and learning-based methods. These maps are evaluated based on their density and accuracy, which are critical for effective structure-from-motion reconstruction commonly utilized in navigation for landing. The results demonstrate that machine learning techniques enhance feature detection and matching, providing more intricate representations of environments with sparse features. This improvement indicates a significant potential for machine learning to boost hazard detection and avoidance in space exploration and other complex applications. Full article

Satellites should be equipped with more and more deployable, large, flexible appendages to improve their service efficiency and reduce launch costs. The spring-driven deployment method of flexible appendages has been widely applied and generates great instantaneous shock loads on satellites, maybe affecting the safety of other flexible appendages, but the current related investigations for satellites with multiple large flexible appendages are insufficient. In this study, the deployment test of the antenna itself was conducted, and the attitude changes in a satellite during antenna deployment were telemetered. Then, a related dynamical model of the satellite was established and verified by the telemetry values of the satellite. Finally, the shock mechanism transmitted to solar arrays was analyzed, and the effect of solar array attitude was discussed. The results show that the simulated method of antenna deployment equivalent to the shock loads tested was thought to be efficient, though it could cause a small non-zero constant of the simulated angular velocities in the antenna deployment direction. The shock-induced moments, except the rotation direction of the solar array drive assembly (SADA), should be highlighted for the antenna deployment dynamic design of satellites, and the solar array attitude has few effects on the shock-induced loads at the SADA. Full article

To address the inherent challenges of deep space exploration, such as communication delays and the unpredictability of spacecraft environments, this study focuses on enhancing spacecraft adaptability and autonomy, which are essential for Autonomous Space Scientific Exploration. A pivotal aspect of this endeavor is the advancement of spacecraft task scheduling, which is integral to increasing spacecraft autonomy. Current research in this domain predominantly revolves around mission timing planning and is primarily executed from ground stations. However, these plans often lack the granularity required for direct implementation by spacecraft. In response, our study proposes an innovative approach to augment spacecraft autonomy, introducing a method that articulately describes mission objectives and resource information. We designed a novel hierarchical task network-timeline (HTN-T) algorithm, an amalgamation of the HTN scheduling method and the distinctive elements of existing research. This algorithm addresses time constraints through horizontal and vertical expansions, building upon the resolution of logical constraints found in conventional planning methods. Furthermore, it introduces a priority-based strategy for resolving resource conflicts in spacecraft tasks. This algorithm is substantiated through validation, including proof-of-principle demonstrations and assessments within a Space–ground Collaborative Management and Control System encompassing both ground and spacecraft operations. The findings indicate that our proposed algorithm achieves high rates of scheduling success and operational efficiency within a feasible timeframe, thus effectively navigating the complexities of autonomous spacecraft task scheduling. Full article

In this study, a modern principal component analysis (PCA) of the chemical properties of lunar soils was conducted. American and Soviet results acquired during the Apollo and Luna missions, respectively, were analyzed and compared. The chemical composition of the lunar soil was the focus of our analysis, the main aim of which was to assess any possible differences between the results provided by the missions in question. The results were visualized in two- and three-dimensional spaces. The use of PCA virtual variables enabled the chemical composition of the lunar soil to be fully visualized—something impossible to achieve using traditional techniques—and key similarities and differences among the properties of the lunar soil samples were determined. The sources of any differences were then conceptualized. The work reported in this paper offers new directions for future studies, especially research into the design of new lunar soil simulants for lunar construction and civil engineering programs. Full article

This study models the subcritical Hopf bifurcation in thermoacoustic Stirling engines using the Stuart–Landau model, highlighting the role of nonlinear dynamics. By inducing self-sustained oscillations and measuring pressure fluctuations across different temperature gradients imposed on the regenerator, we reveal the engine’s transition to a nonlinear domain, characterized by heightened oscillation amplitudes and unique periodic patterns. Interpreted Landau constants and growth rates illuminate the stabilizing effects of nonlinear dynamics, demonstrating the Stuart–Landau model’s applicability in thermoacoustic engine analysis. Our research confirms that this empirically refined model reliably describes oscillation amplitudes and transient phenomena, contributing valuable perspectives for advancing thermoacoustic engine design and operational understanding. Full article

In this paper, simulation modeling was carried out using Sentaurus Technology Computer-Aided Design. Two types of high electron mobility transistors (HEMT), an AlGaN/GaN/AlGaN double heterojunction and AlGaN/GaN single heterojunction, were designed and compared. The breakdown characteristics and damage mechanisms of the two devices under the injection of high-power microwaves (HPM) were studied. The variation in current density and peak temperature inside the device was analyzed. The effect of Al components at different layers of the device on the breakdown of HEMTs is discussed. The effect and law of the power damage threshold versus pulse width when the device was subjected to HPM signals was verified. It was shown that the GaN HEMT was prone to thermal breakdown below the gate, near the carrier channels. A moderate increase in the Al component can effectively increased the breakdown voltage of the device. Compared with the single heterojunction, the double heterojunction HEMT devices were more sensitive to Al components. The high domain-limiting characteristics effectively inhibited the overflow of channel electrons into the buffer layer, which in turn regulated the current density inside the device and improved the temperature distribution. The leakage current was reduced and the device switching characteristics and breakdown voltage were improved. Moreover, the double heterojunction device had little effect on HPM power damage and high damage resistance. Therefore, a theoretical foundation is proposed in this paper, indicating that double heterojunction devices are more stable compared to single heterojunction devices and are more suitable for applications in aviation equipment operating in high-frequency and high-voltage environments. In addition, double heterojunction GaN devices have higher radiation resistance than SiC devices of the same generation. Full article

To overcome the possible gimbal lock problem of the dual-axis satcom-on-the-move (SOTM) antenna, a three-axis tracking satellite SOTM antenna structure appears. The three-axis SOTM antenna is realized by adding a roll axis to the azimuth axis and pitch axis in the dual-axis SOTM structure. There is coupling among the azimuth axis, pitch axis and roll axis in the mechanical structure of the three-axis SOTM antenna, which makes the kinematic modeling of the antenna difficult. This paper introduces a three-axis SOTM antenna kinematic modeling method based on the modified Denavit–Hartenberg (MDH) method, named the new modified Denavit–Hartenberg (NMDH) method. In order to meet the modeling requirements of the MDH method, the NMDH method adds virtual coordinate systems and auxiliary coordinate systems to the three-axis SOTM antenna and obtains the kinematic model of the three-axis SOTM antenna. During the motion of the carrier, the SOTM antenna needs to adjust the antenna pointing in real time according to the changes of the location and attitude of the moving carrier. Therefore, this paper designs a servo control system based on the active disturbance rejection controller (ADRC), introducing a smooth and continuous ADRC $\mathrm{f}\mathrm{a}\mathrm{l}$ function to enhance the tracking speed of the servo control system and reduce the overshoot of the output response. Finally, system experiments were carried out with a 60 cm caliber three-axis SOTM antenna. The experiment results show that the proposed servo control method achieves higher antenna tracking satellite accuracy and better communication effects. Full article

Thrust constitutes a pivotal performance parameter for aircraft engines. Thrust, being an indispensable parameter in control systems, has garnered significant attention, prompting numerous scholars to propose various methods and algorithms for its estimation. However, research methods for estimating the thrust of the micro-turbojet engines used in unmanned aerial vehicles are relatively scarce. Therefore, this paper proposes a thrust estimator for micro-turbojet engines based on DBO (dung beetle optimization) utilizing bidirectional long short-term memory (BiLSTM) and a convolutional neural network (CNN). Furthermore, the efficacy of the proposed model is further validated through comparative analysis with others in this paper. Full article

Flight simulation training is one of the most important methods in early-stage civil aviation flight training. In this regard, flight simulation competitions are effective tools for evaluating the flight skills of trainees. In this study, a model is developed for evaluating the flight skills of trainees by integrating GBDT (Gradient Boosting Decision Tree), PSO (Particle Swarm Optimization), and CNNs (Convolutional Neural Networks). Flight data from simulations is employed for model training. Initially, performance data and scores are gathered from a simulated flight competition platform. The GBDT algorithm is then applied to filter and identify essential flight parameters from the collected data. Subsequently, the PSO-CNN model is utilized to train on the extracted flight parameters. The proposed GBDT-PSO-CNN model achieves a recognition rate of 93.8% on the test dataset. This assessment system is of significant importance for improving the specific maneuvering skill level of flight trainees. Full article

In the vertical take-off and landing (VTOL) state of tiltrotor aircraft, the inlet entrance encounters the incoming airflow at a 90° attack angle, resulting in highly complex internal flow characteristics that are extremely susceptible to gusts. Meanwhile, the flow quality at the inlet exit directly affects the performance of the aircraft’s engine. This work made use of an unsteady numerical simulation method based on sliding meshes to investigate the internal flow characteristics of the inlet during the hover state of a typical tiltrotor aircraft and the effects of head-on gusts on the inlet’s aerodynamic characteristics. The results show that during the hover state, the tiltrotor aircraft inlet features three pairs of transverse vortices and one streamwise vortex at the aerodynamic interface plane (AIP). The transverse vortices generated due to the rotational motion of the air have the largest scale and exert the strongest influence on the inlet’s performance, which is characterized by pronounced unsteady features. Additionally, strong unsteady characteristics are present within the inlet. Head-on gusts mainly affect the mechanical energy and non-uniformity of the air sucked into the inlet by influencing the direction of the rotor’s induced slipstream, thereby impacting the performance of the inlet. The larger head-on gusts have beneficial effects on the performance of the inlet. When the gust velocity reaches 12 m/s, there is a 1.01% increase in the total pressure recovery (σ) of the inlet, a 25.72% decrease in the circumferential distortion index (DC60), and a reduction of 62.84% in the area where the swirl angle |α| exceeds 15°. Conversely, when the gust velocity of head-on gusts reaches 12 m/s in the opposite direction, the inlet’s total pressure recovery decreases by 1.13%, the circumferential distortion index increases by 14.57%, and the area where the swirl angle exceeds 15° increases by 69.59%, adversely affecting the performance of the inlet. Additionally, the presence of gusts alters the unsteady characteristics within the inlet. Full article

The application of space robotic manipulators and heightened autonomy for In-Orbit Servicing (IOS) represents a paramount pursuit for leading space agencies, given the substantial threat posed by space debris to operational satellites and forthcoming space endeavors. This work presents a guidance algorithm based on Deep Reinforcement Learning (DRL) to solve for space manipulator path planning during the motion-synchronization phase with the mission target. The goal is the trajectory generation and control of a spacecraft equipped with a 7-Degrees of Freedom (7-DoF) robotic manipulator, such that its end effector remains stationary with respect to the target point of capture. The Proximal Policy Optimization (PPO) DRL algorithm is used to optimize the manipulator’s guidance law, and the autonomous agent generates the desired joint rates of the robotic arm, which are then integrated and passed to a model-based feedback linearization controller. The agent is first trained to optimize its guidance policy and then tested extensively to validate the results against a simulated environment representing the motion synchronization scenario of an IOS mission. Full article

This paper aims to investigate a new method that uses buoyant gas mixed with air to control the floating height of scientific balloons. Firstly, the static characteristics and thermophysical properties of mixed-gas balloons are analyzed. Subsequently, the inflation model and the thermal-dynamic coupled model are established. Furthermore, based on theoretical research, a GUI program is compiled to simulate the ascent of mixed-gas balloons. Finally, flight tests are conducted. As the balloon volume expands to the maximum, the vertical velocity begins to decay and eventually oscillates around 0 m/s, which is consistent with the simulation. In addition, there is a noticeable shift in which the balloon starts to float after climbing to the target altitude, and the difference values between the test and the simulation are less than 350 m. Moreover, the trajectory results are similar to the prediction, and the errors of the end position are less than 2.5 km in horizontal distance. Consequently, this paper provides guidance for balloon-designated ceiling height technology which can allow a single balloon system to be used for tests at multiple heights. Full article

Unsteady aerodynamic prediction at high angles of attack is of great importance to the design and development of advanced fighters. In this paper, a weighted feature fusion model (WFFM) that combines the state-space model and neural networks is proposed to build an unsteady aerodynamic model for the precise simulation and control of post-stall maneuvers. In the proposed model, the influences of the physical model on neural networks are considered and adjusted by introducing a standardization layer and a new weighting method. A long short-term memory (LSTM) network is used to fuse two mappings: one from flight states to aerodynamic loads, and the other from low-fidelity data to high-fidelity data. Data from wind tunnel oscillation experiments at high angles of attack using a new kind of wire-driven parallel robot and the traditional tail support are used for verifying the proposed aerodynamic model. The output of the WFFM is also compared with predictions from other models, such as the state-space model, single LSTM model, and feature fusion model not including a feature weighting layer. Results demonstrate improved accuracy of the proposed model in the interpolation and extrapolation tests. Furthermore, the WFFM is applied to the flight simulation of F-16 with different control inputs. Compared with conventional models, the WFFM shows improved accuracy and better generalization capability. Full article

To meet the requirements of achieving higher efficiency and lower NOx pollution, the flame temperature in gas turbine combustors increases continually; thus, the effusion-cooling technology has been used to ensure the combustor liner remains within the allowed temperature, by which the combustion characteristics and emission behavior are possibly influenced. In order to investigate the effects of dome cooling air flow on combustion characteristics and NOx emissions, three-dimensional combustion simulations for a swirl-stabilized can-type gas turbine combustor are carried out in this work by using the computational fluid dynamics (CFD) method. Through adjusting the ratio of the dome cooling air flow and the dilution cooling air flow, the characteristics of flow field, temperature distribution and NOx emissions under each work condition are analyzed. At different ratios of the dome-cooling air flow to the total air flow, the flow velocity field in the region near the center of the combustion chamber is not changed much, while the velocity field near the chamber wall shows a more significant difference. The temperature in the outer recirculation zone within the combustion chamber is effectively reduced as the dome cooling air flow increases. By analyzing the distribution characteristics of the concentration of OH*, it is demonstrated that the dome cooling air flow does not have a direct effect on the reaction of combustion. It is also found that as the ratio of the dome cooling air flow to the total air flow increases from 0 to 0.15, the value of the NOx emissions drops from 28.4 to 26.3 ppmv, about a 7.4% decrease. The distribution of the NOx generation rate in the combustion chamber does not vary significantly with the increasing dome cooling air flow. Furthermore, by calculating the residence time in different stages, when the the ratio of the dome cooling air flow to the total air flow varies from 0 to 0.15, the residence time in the pilot stage decreases obviously, from 42 ms to 18 ms. This means that reduction in residence time is the main factor in the decrease of NOx emissions when the dome cooling air flow increases. Full article

Reusable rockets must rely on well-designed Guidance, Navigation and Control (GNC) algorithms. Because they are tested and verified in closed-loop, high-fidelity simulators, emphasizing the strategy to achieve such advanced models is of paramount importance. A wide spectrum of complex dynamic behaviors and their cross-couplings must be captured to achieve sufficiently representative simulations, hence a better assessment of the GNC performance and robustness. This paper focuses on of the main aspects related to the physical (acausal) modeling of reusable rockets, and the integration of these models into a suitable simulation framework oriented towards GNC Validation and Verification (V&V). Firstly, the modeling challenges and the need for physical multibody models are explained. Then, the Vertical Landing Vehicles Library (VLVLib), a Modelica-based library for the physical modeling and simulation of reusable rocket dynamics, is introduced. The VLVLib is built on specific principles that enable quick adaptations to vehicle changes and the introduction of new features during the design process, thereby enhancing project efficiency and reducing costs. Throughout the paper, we explain how these features allow for the rapid development of complex vehicle simulation models by adjusting the selected dynamic effects or changing their fidelity levels. Since the GNC algorithms are normally tested in Simulink^®, we show how simulation models with a desired fidelity level can be developed, embedded and simulated within the Simulink^® environment. Secondly, this work details the modeling aspects of four relevant vehicle dynamics: propellant sloshing, Thrust Vector Control (TVC), landing legs deployment and touchdown. The CALLISTO reusable rocket is taken as study case: representative simulation results are shown and analyzed to highlight the impact of the higher-fidelity models in comparison with a rigid-body model assumption. Full article

CubeSats are designed to optimize applications within the strict constraints of space and power. This paper presents an On-Board Image Enhancement technique for remote sensing payloads, focusing on achieving Auto White Balance (AWB) with limited resources and enhancing the capabilities of small/microsatellites. The study introduces hardware-based techniques, including histogram adjustment, De-Bayer processing, and AWB, all tailored to minimize hardware resource consumption on CubeSats. The integrated 1U CubeSat system comprises a sensor board, an Image Data Processor (IDP) unit, and onboard computing, with a total power consumption estimated at 2.2 W. This system facilitates image capture at a resolution of 1920 × 1200 and utilizes the proposed algorithm for image enhancement on remote sensing payloads to improve the quality of images captured in low-light environments, thereby demonstrating significant advancements in satellite image processing and object-detection capabilities. Full article

The Phase-Change Heat Exchanger Unit in Layered Porous Media (PCEU-LPM) is obtained through frozen pouring processing, and exhibits characteristics such as high thermal conductivity, high latent heat, and high permeability, making it suitable for dissipating heat in airborne electronic devices. This study numerically investigates the impact of aircraft speed acceleration conditions, which lead to weightlessness or overload, on the performance of the PCHEU-LPM, with a particular focus on the influence of natural convection in the liquid-phase region. Initially, a microscale thermal analysis model is established based on the Navier–Stokes equation scanning electron micrograph to calculate the effective thermal conductivity and permeability of the PCHEU-LPM under different porosities. Subsequently, these parameters are incorporated into a macroscale thermal analysis model based on Darcy’s law, employing an average parameter approach. Using the macroscale thermal analysis model, temperature and velocity fields are computed under various porosities, acceleration magnitudes, and directions. The calculation results indicate that as the acceleration increases from α = 0 to α = 10 g, the interface temperature of the PCHTU-LPM decreases by approximately 5.2 K, and the temperature fluctuation decreases by 2.4 K. If the porosity of the PCHTU-LPM is increased from ε = 70% to ε = 85%, the influence of acceleration change on natural convection will be further amplified, resulting in a decrease in the interface temperature of the PCHTU-LPM by approximately 10.2 K and a decrease in temperature fluctuation by 5.8 K. When the acceleration direction is +z, the interface temperature of the PCHTU-LPM is at its lowest, while it is highest when the acceleration direction is −z, with a maximum difference of 15.4 K between the two. When the acceleration direction is ±x and ±y, the interface temperature lies between the former two cases, with the interface temperature slightly higher for ±y compared to ±x, with a maximum difference of 3.9 K between them. Full article

The analysis of flight loads during symmetric aircraft maneuvers is an essential but computationally intensive task in aircraft design. The significant structural elastic deformation in modern aircraft further complicates this work, adding to the computational demands. Therefore, improving the analysis efficiency of flight loads during maneuvers is crucial for accelerating design interactions and shortening the development cycle. This study explores a method for analyzing flight loads in the time domain during maneuvers of elastic aircraft by introducing a database of high-precision rigid-body aerodynamic loads. Furthermore, it combines the gradient-enhanced Kriging model to efficiently predict elastic flight loads during longitudinal maneuvers. The results indicate that the proposed surrogate-based method has high fitting accuracy with significantly improved computational efficiency, providing a new approach for efficient analysis of flight loads during aircraft maneuvers. Full article

The harsh environment during airplane take-off and flights with complex operating conditions require a high dynamic and impact resistance capability of airplane engines. The design, development, and performance evaluation of new turbofan engines are generally performed through numerical simulations before a full-scale model or prototype experiment for certification. Simulations of fan blade containment tests can reduce trial–error testing and are currently the most convenient and inexpensive alternative for design; however, certification failure is always a risk if the calibration of material models is not correctly applied. This work presents a three-dimensional computational model of a turbofan for designing new engines that meet the certification requirements under the blade containment test. Two calibrated Johnson–Cook plasticity and damage laws for Ti64 are assessed in a simulation of a turbofan blade containment test, demonstrating the ability of the models to be used in the safe design of aircraft engine components subjected to dynamic impact loads with large deformations and adequate damage tolerance. Full article
