One-Step Combined-Nanolithography-and-Photolithography for a 2D Photonic Crystal TM Polarizer

1
Department of Electrical Engineering, The University of Texas at Dallas, Richardson, TX 75080, USA
2
Siliconfile Technologies, Inc., Seongnam-si, Gyeonggi-do 463-050, Korea
3
Department of Electrical Engineering, Korea University, Seoul 136-701, Korea
These authors contributed equally to this work.
*
Author to whom correspondence should be addressed.
Received: 6 January 2014 / Revised: 15 April 2014 / Accepted: 21 April 2014 / Published: 29 April 2014
(This article belongs to the Special Issue Micro/Nano Fabrication)
View Full-Text   |   Download PDF [3105 KB, 5 May 2014; original version 29 April 2014]   |

Abstract

Photonic crystals have been widely investigated since they have great potential to manipulate the flow of light in an ultra-compact-scale and enable numerous innovative applications. 2D slab photonic crystals for the telecommunication C band at around 1550 nm have multi-scale structures that are typically micron-scale waveguides and deep sub-micron-scale air hole arrays. Several steps of nanolithography and photolithography are usually used for the fabrication of multi-scale photonic crystals. In this work, we report a one-step lithography process to pattern both micron and deep sub-micron features simultaneously for the 2D slab photonic crystal using combined-nanoimprint-and-photolithography. As a demonstrator, a 2D silicon photonic crystal transverse magnetic (TM) polarizer was fabricated, and the operation was successfully demonstrated.
