Open AccessArticle
Sensors 2015, 15(6), 12260-12272; doi:10.3390/s150612260

Amorphous Silicon p-i-n Structure Acting as Light and Temperature Sensor

1
Department of Information Engineering, Electronics and Telecommunications, "La Sapienza" University of Rome, via Eudossiana 18, 00184 Rome, Italy
2
Department of Astronautics, Electrical and Energetic Engineering, "La Sapienza" University of Rome, via Eudossiana 18, 00184 Rome, Italy
These authors contributed equally to this work.
*
Author to whom correspondence should be addressed.
Academic Editor: Vittorio M.N. Passaro
Received: 31 March 2015 / Revised: 14 May 2015 / Accepted: 14 May 2015 / Published: 26 May 2015
(This article belongs to the Section Physical Sensors)
View Full-Text   |   Download PDF [593 KB, uploaded 27 May 2015]   |

Abstract

In this work, we propose a multi-parametric sensor able to measure both temperature and radiation intensity, suitable to increase the level of integration and miniaturization in Lab-on-Chip applications. The device is based on amorphous silicon p-doped/intrinsic/n-doped thin film junction. The device is first characterized as radiation and temperature sensor independently. We found a maximum value of responsivity equal to 350 mA/W at 510 nm and temperature sensitivity equal to 3.2 mV/K. We then investigated the effects of the temperature variation on light intensity measurement and of the light intensity variation on the accuracy of the temperature measurement. We found that the temperature variation induces an error lower than 0.55 pW/K in the light intensity measurement at 550 nm when the diode is biased in short circuit condition, while an error below 1 K/µW results in the temperature measurement when a forward bias current higher than 25 µA/cm2 is applied. View Full-Text
Keywords: temperature sensors; photosensors; amorphous silicon devices; Lab-on-Chip temperature sensors; photosensors; amorphous silicon devices; Lab-on-Chip
This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
