Sensors 2013, 13(7), 8377-8392; doi:10.3390/s130708377
Article

Development of a Wireless Displacement Measurement System Using Acceleration Responses

1
, 2,* , 1
 and 3
Received: 14 May 2013; in revised form: 31 May 2013 / Accepted: 13 June 2013 / Published: 1 July 2013
(This article belongs to the Section Physical Sensors)
View Full-Text   |   Download PDF [608 KB, uploaded 21 June 2014]   |   Browse Figures
Abstract: Displacement measurements are useful information for various engineering applications such as structural health monitoring (SHM), earthquake engineering and system identification. Most existing displacement measurement methods are costly, labor-intensive, and have difficulties particularly when applying to full-scale civil structures because the methods require stationary reference points. Indirect estimation methods converting acceleration to displacement can be a good alternative as acceleration transducers are generally cost-effective, easy to install, and have low noise. However, the application of acceleration-based methods to full-scale civil structures such as long span bridges is challenging due to the need to install cables to connect the sensors to a base station. This article proposes a low-cost wireless displacement measurement system using acceleration. Developed with smart sensors that are low-cost, wireless, and capable of on-board computation, the wireless displacement measurement system has significant potential to impact many applications that need displacement information at multiple locations of a structure. The system implements an FIR-filter type displacement estimation algorithm that can remove low frequency drifts typically caused by numerical integration of discrete acceleration signals. To verify the accuracy and feasibility of the proposed system, laboratory tests are carried out using a shaking table and on a three storey shear building model, experimentally confirming the effectiveness of the proposed system.
Keywords: displacement estimation; bridge displacement; acceleration; displacement; wireless smart sensor network; structural health monitoring displacement estimation; bridge displacement; acceleration; displacement; wireless smart sensor network; structural health monitoring
This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
