Photoacoustic Signal Enhancement: Towards Utilization of Low Energy Laser Diodes in Real-Time Photoacoustic Imaging

by Rayyan Manwar, Matin Hosseinzadeh, Ali Hariri, Karl Kratkiewicz, Shahryar Noei and Mohammad R. N. Avanaki

Sensors 2018, 18(10), 3498; https://doi.org/10.3390/s18103498 - 17 Oct 2018

Cited by 57 | Viewed by 3870

Abstract

In practice, photoacoustic (PA) waves generated with cost-effective and low-energy laser diodes, are weak and almost buried in noise. Reconstruction of an artifact-free PA image from noisy measurements requires an effective denoising technique. Averaging is widely used to increase the signal-to-noise ratio (SNR) [...] Read more.

In practice, photoacoustic (PA) waves generated with cost-effective and low-energy laser diodes, are weak and almost buried in noise. Reconstruction of an artifact-free PA image from noisy measurements requires an effective denoising technique. Averaging is widely used to increase the signal-to-noise ratio (SNR) of PA signals; however, it is time consuming and in the case of very low SNR signals, hundreds to thousands of data acquisition epochs are needed. In this study, we explored the feasibility of using an adaptive and time-efficient filtering method to improve the SNR of PA signals. Our results show that the proposed method increases the SNR of PA signals more efficiently and with much fewer acquisitions, compared to common averaging techniques. Consequently, PA imaging is conducted considerably faster. Full article

(This article belongs to the Special Issue Photoacoustic Sensing and Imaging in Biomedicine)
