Open AccessArticle
Appl. Sci. 2018, 8(2), 212; doi:10.3390/app8020212

Variety Identification of Single Rice Seed Using Hyperspectral Imaging Combined with Convolutional Neural Network

College of Biosystems Engineering and Food Science, Zhejiang University, 866 Yuhangtang Road, Hangzhou 310058, China
Key Laboratory of Spectroscopy Sensing, Ministry of Agriculture, Hangzhou 310058, China
Author to whom correspondence should be addressed.
Received: 31 December 2017 / Revised: 28 January 2018 / Accepted: 29 January 2018 / Published: 31 January 2018
(This article belongs to the Special Issue Hyperspectral Chemical Imaging for Food Authentication)
View Full-Text   |   Download PDF [1727 KB, uploaded 31 January 2018]   |


The feasibility of using hyperspectral imaging with convolutional neural network (CNN) to identify rice seed varieties was studied. Hyperspectral images of 4 rice seed varieties at two different spectral ranges (380–1030 nm and 874–1734 nm) were acquired. The spectral data at the ranges of 441–948 nm (Spectral range 1) and 975–1646 nm (Spectral range 2) were extracted. K nearest neighbors (KNN), support vector machine (SVM) and CNN models were built using different number of training samples (100, 200, 300, 400, 500, 600, 700, 800, 900, 1000, 1500, 2000, 2500 and 3000). KNN, SVM and CNN models in the Spectral range 2 performed slightly better than those in the Spectral range 1. The model performances improved with the increase in the number of training samples. The improvements were not significant when the number of training samples was large. CNN model performed better than the corresponding KNN and SVM models in most cases, which indicated the effectiveness of using CNN to analyze spectral data. The results of this study showed that CNN could be adopted in spectral data analysis with promising results. More varieties of rice need to be studied in future research to extend the use of CNNs in spectral data analysis. View Full-Text
Keywords: hyperspectral imaging; variety identification; rice seed; convolutional neural network hyperspectral imaging; variety identification; rice seed; convolutional neural network

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
