Open AccessArticle
Micromachines 2015, 6(9), 1331-1345;

Microfluidic Induced Controllable Microdroplets Assembly in Confined Channels

Institute of Electronic Paper Displays, South China Academy of Optoelectronics, South China Normal University, Guangzhou 510006, China
Author to whom correspondence should be addressed.
Academic Editors: Andrew deMello and Xavier Casadevall i Solvas
Received: 25 July 2015 / Revised: 27 August 2015 / Accepted: 1 September 2015 / Published: 10 September 2015
(This article belongs to the Special Issue Droplet Microfluidics: Techniques and Technologies)
View Full-Text   |   Download PDF [6686 KB, uploaded 10 September 2015]   |


We report on the microfluidic induced monodispersed microdroplet generation and assembly in confined microchannels. Two and three dimensional close-packed droplet lattices were obtained in microfluidic devices by adjusting the channel geometry, the fluidic flow rates and the monodispersed droplet size. The droplet packing was mainly caused by the volumetric effect and capillarity in confined microchannels. Polymerizable fluids were also investigated to demonstrate the effect of fluidic properties on the microdroplet generation and assembly, which could find interesting applications in the future. This approach would be helpful to fundamentally understand the mechanism of self-assembly process of particles in confined microstructures, and practically be applied in sensing and energy storage devices. View Full-Text
Keywords: microfluidics; microdroplet; self-assembly; close-packed configuration microfluidics; microdroplet; self-assembly; close-packed configuration

Figure 1
