Broadband Transformation Optics Devices

1,* , 2
, 3
 and 3
Received: 12 October 2010; in revised form: 18 October 2010 / Accepted: 20 October 2010 / Published: 21 October 2010
(This article belongs to the Special Issue Next Wave of Metamaterials)
Download PDF [2055 KB, uploaded 21 October 2010]
Abstract: Recently we have suggested that two-dimensional broadband transformation optics devices based on metamaterial designs may be built using tapered waveguides. Here we review application of this principle to broadband electromagnetic cloaking, trapped rainbow, and novel microscopy devices.
Keywords: metamaterial; transformation optics; microscopy metamaterial; transformation optics; microscopy
