Mar. Drugs 2013, 11(3), 881-895; doi:10.3390/md11030881

Improved Detection of Domoic Acid Using Covalently Immobilised Antibody Fragments

1 Microbiology, NUI Galway, University Road, Galway, Ireland 2 Network of Excellence for Functional Biomaterials (NFB), NUI Galway, University Road, Galway, Ireland
* Author to whom correspondence should be addressed.
Received: 26 December 2012 / Revised: 13 January 2013 / Accepted: 21 February 2013 / Published: 14 March 2013
(This article belongs to the Special Issue Marine Neurotoxins)
View Full-Text   |   Download PDF [312 KB, uploaded 24 February 2015]   |   Browse Figures


Antibody molecules, and antibody fragments in particular, have enormous potential in the development of biosensors for marine monitoring. Conventional immobilisation approaches used in immunoassays typically yield unstable and mostly incorrectly oriented antibodies, however, resulting in reduced detection sensitivities for already low concentration analytes. The 2H12 anti-domoic acid scFv antibody fragment was engineered with cysteine-containing linkers of two different lengths, distal to the antigen binding pocket, for covalent and correctly oriented immobilisation of the scFvs on functionalised solid supports. The Escherichia coli-produced, cysteine-engineered scFvs dimerised in solution and demonstrated similar efficiencies of covalent immobilisation on maleimide-activated plates and minimal non-covalent attachment. The covalently attached scFvs exhibited negligible leaching from the support under acidic conditions that removed almost 50% of the adsorbed wildtype fragment, and IC50s for domoic acid of 270 and 297 ng/mL compared with 1126 and 1482 ng/mL, respectively, for their non-covalently adsorbed counterparts. The expression and immobilisation approach will facilitate the development of stable, reusable biosensors with increased stability and detection sensitivity for marine neurotoxins.
Keywords: domoic acid; scFv antibody fragment; covalent immobilisation; protein engineering; cysteine domoic acid; scFv antibody fragment; covalent immobilisation; protein engineering; cysteine
This is an open access article distributed under the Creative Commons Attribution License (CC BY) which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.

Share & Cite This Article

Further Mendeley | CiteULike
Export to BibTeX |
EndNote |
MDPI and ACS Style

Hortigüela, M.J.; Wall, J.G. Improved Detection of Domoic Acid Using Covalently Immobilised Antibody Fragments. Mar. Drugs 2013, 11, 881-895.
