Open AccessTechnical Note
Sensors 2017, 17(7), 1638; doi:10.3390/s17071638

Flexible Boron-Doped Diamond (BDD) Electrodes for Plant Monitoring

1
Photocatalyst Group, Research and Development Department, Local Independent Administrative Agency Kanagawa Institute of industrial Science and TEChnology (KISTEC), 407 East Wing, Innovation Center Building, KSP, 3-2-1 Sakado, Takatsu-ku, Kawasaki, Kanagawa 213-0012, Japan
2
Materials Analysis Group, Kawasaki Technical Support Department, KISTEC, Ground Floor East Wing, Innovation Center Building, KSP, 3-2-1 Sakado, Takatsu-ku, Kawasaki, Kanagawa 213-0012, Japan
3
Photocatalysis International Research Centre, Tokyo University of Science, 2641 Yamazaki, Noda, Chiba 278-8510, Japan
4
Nippon Institute of Technology, 4-1 Gakuendai, Miyashiro-machi, Minamisaitama-gun, Saitama 345-8501, Japan
*
Author to whom correspondence should be addressed.
Received: 17 June 2017 / Revised: 7 July 2017 / Accepted: 13 July 2017 / Published: 15 July 2017
(This article belongs to the Special Issue Advanced Sensors Based on Carbon Electrodes)
View Full-Text   |   Download PDF [13451 KB, uploaded 25 July 2017]   |

Abstract

Detecting the bio-potential changes of plants would be useful for monitoring their growth and health in the field. A sensitive plant monitoring system with flexible boron-doped diamond (BDD) electrodes prepared from BDD powder and resin (Nafion or Vylon-KE1830) was investigated. The properties of the electrodes were compared with those of small BDD plate-type electrodes by monitoring the bioelectric potentials of potted Aloe and hybrid species in the genus Opuntia. While flexible BDD electrodes have wide potential windows, their cyclic voltammograms are different from those of the BDD plate. Further, the potential gap between a pair of electrodes attached to the plants changes as the plants are stimulated artificially with a finger touch, suggesting that the bioelectric potentials in the plant also changed, manifesting as changes in the potential gap between the electrodes. The BDD electrodes were assessed for their response reproducibility to a finger stimulus for 30 days. It was concluded that the plant monitoring system worked well with flexible BDD electrodes. Further, the electrodes were stable, and as reliable as the BDD plate electrodes in this study. Thus, a flexible and inexpensive BDD electrode system was successfully fabricated for monitoring the bioelectric potential changes in plants. View Full-Text
Keywords: boron-doped diamond (BDD) electrode; bioelectric potentials; plant monitoring; flexible sensor electrode boron-doped diamond (BDD) electrode; bioelectric potentials; plant monitoring; flexible sensor electrode
Figures

Figure 1
