Wide-Spectrum Microscope with a Long Working Distance Aspherical Objective Based on Obscuration Constraint

1,2,* , 1,* , 1
and
1
1
Institute of Ultra-Precision Optoelectronic Instrument Engineering, Harbin Institute of Technology, Harbin 150001, China
2
Department of Engineering Science, University of Oxford, ParksRoad, Oxford OX1 3PJ, UK
*
Authors to whom correspondence should be addressed.
Academic Editor: Vittorio M. N. Passaro
Received: 26 September 2016 / Revised: 5 November 2016 / Accepted: 7 November 2016 / Published: 9 November 2016
(This article belongs to the Section Physical Sensors)
View Full-Text   |   Download PDF [4771 KB, uploaded 9 November 2016]   |

Abstract

We present an approach for an initial configuration design based on obscuration constraint and on-axis Taylor series expansion to realize the design of long working distance microscope (numerical aperture (NA) = 0.13 and working distance (WD) = 525 mm) with a low obscuration aspherical Schwarzschild objective in wide-spectrum imaging (λ = 400–900 nm). Experiments of the testing on the resolution target and inspection on United States Air Force (USAF) resolution chart and a line charge-coupled device (CCD) (pixel size of 14 μm × 56 μm) with different wavelength light sources (λ = 480 nm, 550 nm, 660 nm, 850 nm) were implemented to verify the validity of the proposed method. View Full-Text
Keywords: wide-spectrum microscope; aspherical Schwarzschild objective; low obscuration; long working distance wide-spectrum microscope; aspherical Schwarzschild objective; low obscuration; long working distance
Figures

Figure 1
