Sensors 2015, 15(4), 8527-8539; doi:10.3390/s150408527

Measurement Method of Magnetic Field for the Wire Suspended Micro-Pendulum Accelerometer

1
Key Lab. of Opto-Electronic Technology & System, Ministry of Education, Chongqing University, Chongqing 400044, China
2
State Key Lab. of Information Engineering in Surveying, Mapping and Remote Sensing, Wuhan University, Wuhan 430079, China
3
College of Aerospace Engineering, Chongqing University, Chongqing 400044, China
*
Author to whom correspondence should be addressed.
Academic Editor: Vittorio M.N. Passaro
Received: 4 February 2015 / Revised: 19 March 2015 / Accepted: 7 April 2015 / Published: 13 April 2015
(This article belongs to the Section Physical Sensors)
View Full-Text   |   Download PDF [1968 KB, uploaded 13 April 2015]   |

Abstract

Force producer is one of the core components of a Wire Suspended Micro-Pendulum Accelerometer; and the stability of permanent magnet in the force producer determines the consistency of the acceleration sensor’s scale factor. For an assembled accelerometer; direct measurement of magnetic field strength is not a feasible option; as the magnetometer probe cannot be laid inside the micro-space of the sensor. This paper proposed an indirect measurement method of the remnant magnetization of Micro-Pendulum Accelerometer. The measurement is based on the working principle of the accelerometer; using the current output at several different scenarios to resolve the remnant magnetization of the permanent magnet. Iterative Least Squares algorithm was used for the adjustment of the data due to nonlinearity of this problem. The calculated remnant magnetization was 1.035 T. Compared to the true value; the error was less than 0.001 T. The proposed method provides an effective theoretical guidance for measuring the magnetic field of the Wire Suspended Micro-Pendulum Accelerometer; correcting the scale factor and temperature influence coefficients; etc. View Full-Text
Keywords: Wire Suspended Micro-Pendulum Accelerometer; magnetic field strength; permanent magnet; iterative least squares Wire Suspended Micro-Pendulum Accelerometer; magnetic field strength; permanent magnet; iterative least squares
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
