Sensors 2013, 13(9), 11539-11552; doi:10.3390/s130911539
Article

Research on the Dynamic Hysteresis Loop Model of the Residence Times Difference (RTD)-Fluxgate

1,2
, 1,2,* , 1,2
, 1,2
, 1,2
 and 1,2
Received: 12 July 2013; in revised form: 26 August 2013 / Accepted: 27 August 2013 / Published: 2 September 2013
(This article belongs to the Section Physical Sensors)
View Full-Text   |   Download PDF [749 KB, uploaded 21 June 2014]   |   Browse Figures
Abstract: Based on the core hysteresis features, the RTD-fluxgate core, while working, is repeatedly saturated with excitation field. When the fluxgate simulates, the accurate characteristic model of the core may provide a precise simulation result. As the shape of the ideal hysteresis loop model is fixed, it cannot accurately reflect the actual dynamic changing rules of the hysteresis loop. In order to improve the fluxgate simulation accuracy, a dynamic hysteresis loop model containing the parameters which have actual physical meanings is proposed based on the changing rule of the permeability parameter when the fluxgate is working. Compared with the ideal hysteresis loop model, this model has considered the dynamic features of the hysteresis loop, which makes the simulation results closer to the actual output. In addition, other hysteresis loops of different magnetic materials can be explained utilizing the described model for an example of amorphous magnetic material in this manuscript. The model has been validated by the output response comparison between experiment results and fitting results using the model.
Keywords: RTD-fluxgate core; hysteresis loop; arctangent model; simulation of the output response RTD-fluxgate core; hysteresis loop; arctangent model; simulation of the output response
This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
