Sensors 2012, 12(10), 14041-14052; doi:10.3390/s121014041

Thermoresponsive Magnetic Nano-Biosensors for Rapid Measurements of Inorganic Arsenic and Cadmium

1 United Graduate School of Agricultural Science, Tokyo University of Agriculture and Technology, 3-5-8 Saiwaicho, Fuchu 183-8509, Japan 2 Faculty of Agriculture, Utsunomiya University, 350 Minemachi, Utsunomiya 321-8505, Japan
* Author to whom correspondence should be addressed.
Received: 9 July 2012 / Revised: 3 September 2012 / Accepted: 8 October 2012 / Published: 18 October 2012
View Full-Text   |   Download PDF [397 KB, uploaded 21 June 2014]   |   Browse Figures


Green fluorescent protein-tagged sensor proteins, ArsR-GFP and CadC-GFP, have been produced as biosensors for simple and low-cost quantification of As(III) or Cd(II). In this study, the sensor protein-promoter DNA complexes were reconstructed on the surfaces of magnetic particles of different sizes. After the surface modification all the particles could be attracted by magnets, and released different amounts of GFP-tagged protein, according to the metal concentrations within 5 min, which caused significant increases in fluorescence. A detection limit of 1 µg/L for As(III) and Cd(II) in purified water was obtained only with the nanoparticles exhibiting enough magnetization after heat treatment for 1 min. Therefore, thermoresponsive magnetic nano-biosensors offer great advantages of rapidity and sensitivity for the measurement of the toxic metals in drinking water.
Keywords: magnetic nanoparticles; heavy metal; biosensor; ArsR; CadC; GFP magnetic nanoparticles; heavy metal; biosensor; ArsR; CadC; GFP
This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
