Sensors 2011, 11(8), 7710-7723; doi:10.3390/s110807710
Article

FPGA-Based Smart Sensor for Online Displacement Measurements Using a Heterodyne Interferometer

1 HSPdigital, CA Procesamiento Digital de SeƱales, CA Telematica, DICIS, Universidad de Guanajuato, Carr. Salamanca-Valle km 3.5+1.8, Palo Blanco, 36885 Salamanca, Gto., Mexico 2 HSPdigital, CA Mecatronica, Facultad de Ingenieria, Campus San Juan del Rio, Universidad Autonoma de Queretaro, Rio Moctezuma 249, 76807 San Juan del Rio, Qro., Mexico
* Author to whom correspondence should be addressed.
Received: 10 June 2011; in revised form: 2 August 2011 / Accepted: 4 August 2011 / Published: 5 August 2011
(This article belongs to the Section Physical Sensors)
PDF Full-text Download PDF Full-Text [1497 KB, uploaded 5 August 2011 16:08 CEST]
Abstract: The measurement of small displacements on the nanometric scale demands metrological systems of high accuracy and precision. In this context, interferometer-based displacement measurements have become the main tools used for traceable dimensional metrology. The different industrial applications in which small displacement measurements are employed requires the use of online measurements, high speed processes, open architecture control systems, as well as good adaptability to specific process conditions. The main contribution of this work is the development of a smart sensor for large displacement measurement based on phase measurement which achieves high accuracy and resolution, designed to be used with a commercial heterodyne interferometer. The system is based on a low-cost Field Programmable Gate Array (FPGA) allowing the integration of several functions in a single portable device. This system is optimal for high speed applications where online measurement is needed and the reconfigurability feature allows the addition of different modules for error compensation, as might be required by a specific application.
Keywords: smart sensor; FPGA; heterodyne interferometer; phase measurement
