High Electron Mobility Transistor (HEMT) Devices and Applications

A special issue of Crystals (ISSN 2073-4352). This special issue belongs to the section "Materials for Energy Applications".

Deadline for manuscript submissions: closed (31 March 2024) | Viewed by 4759

Special Issue Editors

Dr. Weiyi Li

E-Mail Website
Guest Editor
Department of Electrical and Computer Engineering, University of California, Santa Barbara, CA 93106, USA
Interests: GaN; HEMTs; wide bandgap material; RF transistor; power electronics; transistor modeling
Dr. Houqiang Fu

E-Mail Website
Guest Editor
School of Electrical, Computer and Energy Engineering, Arizona State University, Tempe City, AZ 85281, USA
Interests: wide and ultrawide bandgap semiconductors; power electronics; optoelectronics; extreme-environment devices
Special Issues, Collections and Topics in MDPI journals

Special Issue Information

Dear Colleagues,

Ever since the demonstration of the first high-electron mobility transistors (HEMTs) by Dr. Mimura in 1981, HEMTs have been developed rapidly and commercialized in different material systems for a myriad of applications. At the early development stage, AlGaAs/GaAs, GaAs/InGaAs, and InP-based HEMTs were widely implemented into high-speed electronics communication applications with excellent noise and power performance. The development of GaN HEMTs has opened the gate to more applications, such as power electronics, mm-wave frequency systems, biosensing, and radiation-hardened electronics. Recently, ultrawide bandgap materials such as AlGaN- and Ga2O3-based HEMTs have been introduced and demonstrated encouraging results. This Special Issue will cover innovative HEMT devices, applications based on HEMT technology, HEMT-related material research, including epitaxy growth, material characterization, and fabrication techniques, and HEMT simulation.

Dr. Weiyi Li
Prof. Dr. Houqiang Fu
Guest Editors

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Crystals is an international peer-reviewed open access monthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2100 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • high-electron mobility transistors
  • HEMT simulation
  • HEMT applications
  • HEMT heterostructure
  • gallium nitride
  • gallium arsenide
  • indium phosphide
  • ultrawide bandgap semiconductors

Benefits of Publishing in a Special Issue

  • Ease of navigation: Grouping papers by topic helps scholars navigate broad scope journals more efficiently.
  • Greater discoverability: Special Issues support the reach and impact of scientific research. Articles in Special Issues are more discoverable and cited more frequently.
  • Expansion of research network: Special Issues facilitate connections among authors, fostering scientific collaborations.
  • External promotion: Articles in Special Issues are often promoted through the journal's social media, increasing their visibility.
  • e-Book format: Special Issues with more than 10 articles can be published as dedicated e-books, ensuring wide and rapid dissemination.

Further information on MDPI's Special Issue polices can be found here.

Published Papers (2 papers)

Download All Papers
Order results
Result details
Show export options expand_more Show export options expand_less
Select all
Export citation of selected articles as:

Research

9 pages, 5739 KiB
Article
High-Performance N-Polar GaN/AlGaN Metal–Insulator–Semiconductor High-Electron-Mobility Transistors with Low Surface Roughness Enabled by Chemical–Mechanical-Polishing-Incorporated Layer Transfer Technology
by Bohan Guo, Guohao Yu, Li Zhang, Jiaan Zhou, Zheming Wang, Runxian Xing, An Yang, Yu Li, Bosen Liu, Xiaohong Zeng, Zhongkai Du, Xuguang Deng, Zhongming Zeng and Baoshun Zhang
Crystals 2024, 14(3), 253; https://doi.org/10.3390/cryst14030253 - 4 Mar 2024
Viewed by 1877
Abstract
This article presents the utilization of the chemical–mechanical polishing (CMP) method to fabricate high-performance N-polar GaN/AlGaN metal–insulator–semiconductor high-electron-mobility transistors (MIS-HEMTs) through layer transfer technology. The nucleation and buffer layers were removed via CMP to attain a pristine N-polar GaN surface with elevated smoothness, [...] Read more.
This article presents the utilization of the chemical–mechanical polishing (CMP) method to fabricate high-performance N-polar GaN/AlGaN metal–insulator–semiconductor high-electron-mobility transistors (MIS-HEMTs) through layer transfer technology. The nucleation and buffer layers were removed via CMP to attain a pristine N-polar GaN surface with elevated smoothness, featuring a low root-mean-square (RMS) roughness of 0.216 nm. Oxygen, carbon, and chlorine impurity elements content were low after the CMP process, as detected via X-ray photoelectron spectroscopy (XPS). The electrical properties of N-polar HEMTs fabricated via CMP exhibited a sheet resistance (Rsh) of 244.7 Ω/sq, a mobility of 1230 cm2/V·s, and an ns of 2.24 × 1013 cm−2. Compared with a counter device fabricated via inductively coupled plasma (ICP) dry etching, the CMP devices showed an improved output current of 756.1 mA/mm, reduced on-resistance of 6.51 Ω·mm, and a significantly reduced subthreshold slope mainly attributed to the improved surface conditions. Meanwhile, owing to the MIS configuration, the reverse gate leakage current could be reduced to as low as 15 μA/mm. These results highlight the feasibility of the CMP-involved epitaxial layer transfer (ELT) technique to deliver superior N-polar GaN MIS-HEMTs for power electronic applications. Full article
(This article belongs to the Special Issue High Electron Mobility Transistor (HEMT) Devices and Applications)
►▼ Show Figures

Figure 1

10 pages, 3242 KiB
Communication
Highly Reliable Temperature Sensor Based on p-GaN/AlGaN/GaN Hybrid Anode Diode with Wide Operation Temperature from 73 K to 573 K
by An Yang, Xing Wei, Wenchao Shen, Yu Hu, Tiwei Chen, Heng Wang, Jiaan Zhou, Runxian Xing, Xiaodong Zhang, Guohao Yu, Yaming Fan, Yong Cai, Zhongming Zeng and Baoshun Zhang
Crystals 2023, 13(4), 620; https://doi.org/10.3390/cryst13040620 - 4 Apr 2023
Cited by 2 | Viewed by 1714
Abstract
A high-performance temperature sensor based on a p-GaN/AlGaN/GaN hybrid anode diode (HPT-HAD) fabricated by hydrogen plasma treatment is demonstrated. The sensor exhibits accurate and stable temperature responses from 73 to 573 K. The forward anode voltage is linearly proportional to the temperature over [...] Read more.
A high-performance temperature sensor based on a p-GaN/AlGaN/GaN hybrid anode diode (HPT-HAD) fabricated by hydrogen plasma treatment is demonstrated. The sensor exhibits accurate and stable temperature responses from 73 to 573 K. The forward anode voltage is linearly proportional to the temperature over the measured temperature range at a fixed current. At a forward current density of 10−7 mA/mm, the device achieves a maximum sensitivity of 1.93 mV/K. The long-time anode current stress measurement reveals that the HPT-HAD shows almost no degradation even at 573 K for 1 h at a current of 100 μA, and the anode voltage shifts only 120 mV at 573 K for 1000 s at 1 nA. This work shows that the HPT-HAD temperature sensor can be reliably operated over a wide temperature range from cryogenic to high temperatures, so can be used in a variety of extreme environments. Full article
(This article belongs to the Special Issue High Electron Mobility Transistor (HEMT) Devices and Applications)
►▼ Show Figures

Figure 1
