Seed Micromorphology, In Vitro Germination, and Early-Stage Seedling Morphological Traits of Cattleya purpurata (Lindl. & Paxton) Van den Berg

by
Miriam Bazzicalupo
1,*,
Jacopo Calevo
2,*,
Martino Adamo
2,3,
Annalisa Giovannini
4,
Andrea Copetta
4 and
Laura Cornara
1
1
Department of Earth, Environment and Life Sciences, University of Genoa, Corso Europa 26, 16132 Genoa, Italy
2
Department of Life Sciences and Systems Biology, University of Turin, Viale Mattioli 25, 10125 Turin, Italy
3
Ecologie Microbienne, UCBL, CNRS, INRA, University of Lyon 1, Boulevard du 11 Novembre 1918 43, 69622 Villeurbanne, France
4
CREA Research Centre for Vegetable and Ornamental Crops, Council for Agricultural Research and Economics, Corso degli Inglesi 508, 18038 Sanremo, Italy
*
Authors to whom correspondence should be addressed.
Horticulturae 2021, 7(11), 480; https://doi.org/10.3390/horticulturae7110480
Submission received: 11 October 2021 / Revised: 5 November 2021 / Accepted: 8 November 2021 / Published: 10 November 2021
(This article belongs to the Special Issue Feature Papers in Horticulturae Ⅱ)
Browse Figures
Versions Notes

Abstract

:
In the context of a symbiotic plant-fungus interaction study concerning Cattleya purpurata, we focused on some aspects of seed morphology and biology, and the early stages of seedling development. Seed morphology was characterized using light and scanning electron microscopy. In vitro seed germination capability was evaluated, comparing symbiotic and asymbiotic methods. The morphology of the seeds was overall comparable to that of other congeneric species, showing classical adaptations related to the aerodynamic properties and to the wettability of seeds, but calcium oxalate druses were identified inside the suspensor cells. Asymbiotic seed germination was successful in all tested media (17.1–46.5%) but was higher on 1/2 Murashige & Skoog. During symbiotic interaction with the fungal strain MUT4178 (Tulasnella calospora), germination rate was significantly lower than that obtained with the best three asymbiotic media, suggesting a low fungal compatibility. Seedling morphology was in line with other taxa from the same genus, showing typical characteristics of epiphytic species. Our observations, in particular, highlighted the presence of stomata with C-shaped guard cells in the leaves, rarely found in Cattleyas (where usually they are reniform), and confirm the presence of tilosomes in the roots. Idioblasts containing raphides were observed in both roots and leaves.

Graphical Abstract

1. Introduction

Orchidaceae, with about 28,000 species and new ones being discovered every year, is one of the largest families of flowering plants [1]. The great majority of species is native to tropical or sub-tropical areas, but the family can be considered cosmopolitan, being spread over the five continents, with a distribution range that extends from the Arctic Circle to sub-Antarctic islands [2]. Orchids have interesting and often strict interactions with specialized pollinators and mycorrhizal fungi [3,4,5], and are at risk of extinction by intrinsic and extrinsic factors linked with habitat degradation [6], including weed invasion, grazing, altered hydrology, and altered fire regimes.
Among the Epidendroideae subfamily, the subtribe Laeliinae is strictly neotropical and comprises about 50 genera with about 1500 species [7,8]; it is one of the largest subtribes in the family after Pleurothallidinae and Oncidiinae [9]. Due to its morphological variability and taxonomic divergence [9], Laeliinae has been the subject of great taxonomic reviews over the last few decades; in this subtribe, Dressler [7] included the genera Cattleya Lindl., Laelia Lindl., Schomburgkia Lindl., and Sophronitis Lindl. Van den Berg et al. [9,10], thanks to a phylogenetic analysis on ITS regions and considering the hybridization capability within Laeliinae, supported the inclusion of Schomburgkia and Sophronitis species in Laelia and Cattleya, respectively. For the above-mentioned reasons, Brazilian Laelia species, previously referred to as Hadrolaelia [11], have also been included in the genus Cattleya [12].
Cattleya purpurata (Lindl. & Paxton) Van den Berg (syn. Laelia purpurata) is a Brazilian orchid species that grows widely in the country and has been ranked as endangered (EN) by IUCN (International Union for Conservation of Nature) in the State of Rio Grande do Sul [13], due to its over-collection for commercial purpose [14]. The species has been the focus of many studies due to its high economical value; it is considered one of the flag flowers of Brazil and nowadays it is in collections all over the World, with several cultivars and varieties [15]. As recently reported by Caballero-Villalobos et al. [16], the species is nectarless and self-compatible, although it is pollinator-dependent. Some morphological investigations on the vegetative portions of this species have been carried out by Silva Júnior et al. [17] and Gallo et al. [18]. The former studied leaf characteristics and chlorophyll content of this species after the applications of different urea concentrations during in vitro experiments. Gallo et al. [18] performed an anatomical investigation on seed and protocorm from six species belonging to the genus Cattleya, C. purpurata included. Anatomical investigations provide important information to assess species identity, to better understand physiological processes, or to study phylogenetic relationships between taxa [19]. This information, which can be achieved considering both the vegetative and reproductive portions of a species, could also be used to improve knowledge and be applied in micropropagation techniques and conservation programs [18].
New propagation techniques have been proposed over the last decades to optimize asymbiotic and symbiotic seed germination, and to promote seedling acclimatization [15,20,21]. However, contrary to what is known about terrestrial species [22,23,24], few details are available concerning mycorrhizal associations in tropical orchids, especially in Laeliinae occurring in different environments (i.e., [25,26]).
In this work, which has been carried out in the framework of a plant-fungus interaction study [27], our aim was to obtain more morphological information regarding C. purpurata seed traits and test seed germination via both asymbiotic and symbiotic techniques, in the latter case using a fungal strain of the well-known orchid mycorrhizal (OM) fungus Tulasnella calospora. Seedlings grown on different media and growth conditions were then characterized from an anatomical and micro-morphological point of view in order to collect further data concerning this stage of development and to improve propagation techniques to be used in scientific and conservation programs.

2. Materials and Methods

2.1. Flower Hand Pollination and Seed Collection

Capsules were obtained by hand pollinated plants of Cattleya purpurata cultivated by the Azienda Agricola Nardotto e Capello in Camporosso (Imperia, Italy), 43°48′18″00 N, 07°37′43″32 E. At the time of capsule maturation, indicated by a yellowish color, three capsules were collected, and seeds were stored at 4 °C in a paper envelop until use [28].

2.2. Seed Sowing

After a sterilization in 1% NaClO solution, seeds were rinsed three times in sterile dH2O for 5 min and then sowed on six different asymbiotic seed germination media: 1/2 strength of Murashige and Skoog [29], including vitamins (Duchefa) enriched with 50 mL/L of coconut water; Knudson C [30] orchid medium (Duchefa); Malmgren Modified medium [31]; M551 (Phytotechnology) enriched with 1mg/L BAP, which are commonly used for the propagation of epiphytic and terrestrial orchids [32]; and CG (CG0) and CG enriched with 50 mL/L (CG50) and 100 mL/L (CG100) almond milk, a new medium that showed to improve in vitro seedling development in both epiphytic and terrestrial orchids [32]. All the media were supplemented with 2 g/L of activated charcoal and a total concentration of 10 g/L of sucrose; pH was adjusted to 5.8. Seeds were also sowed on an oat agar medium (OA), as described by Ercole et al. [33], with a mycorrhizal fungal strain of Tulasnella calospora, isolated at the University of Turin from Serapias vomeracea [34] and deposited in the mycological collection of the University of Turin (Mycotheca Universitatis Taurinensis, accession number MUT4178). Eight replicates for each medium were periodically checked under light microscope to assess germination percentage. The final germination percentage, recorded 70 days after seed sowing, was evaluated as the overall mean of single observations ± SE. Seedlings were then moved to jars with the same media for three months before recording morphological data.

2.3. Microscopy

2.3.1. Plant Material

Nine months after sowing (after transferring seedlings on fresh media every three months), fully developed roots and leaves from each medium were sampled. Roots and leaves were cut about 1 cm from the apex and about half of their length, respectively. Plant material was prepared to perform micro-morphological investigations according to the following methods.

2.3.2. Light Microscopy

Light microscopy (LM) analysis was carried out on seeds, seedling leaves, and roots. Seeds were directly mounted onto a microscope slide after being rinsed in 5% NaClO solution for 1 h, and were then observed with a Leica DM 2000 transmission-light microscope coupled with a computer-driven DFC 320 camera (Leica Microsystems). Seed and embryo length, length/width (L/W) ratio, number of cells along the entire seed longitudinal axis, and length and number of cells of the suspensor were recorded for 100 seeds. Seed descriptive terminology has been used according to Barthlott et al. [35].
Transversal hand-sections of fresh leaves and roots obtained by a razor blade were stained with both TBO (Toluidine Blue O), to discriminate cell wall structures, and acid Phloroglucinol, to highlight xylem and lignified structures in general. The seeds and transversal sections of leaf and roots were also examined under a polarizing filter. In addition, to localize suberin and lignin, transversal sections of roots were stained with Fluorol Yellow 088 and observed under UV light.

2.3.3. Scanning Electron Microscopy

Seeds were incubated overnight in 100% ethanol, placed on aluminum stubs covered with double-sided carbon tape, and dried at room temperature, as performed by Calevo et al. [36]. Stubs were then sputter-coated with 10 nm gold particles and directly observed with a Vega3 Tescan LMU Scanning Electron Microscope (SEM) (Tescan USA Inc., Cranberry Twp, PA, USA) at an accelerating voltage of 20 kV, coupled to an X-ray Energy Dispersive System (EDS) Apollo XSD (Tescan USA Inc., Warrendale, PA, USA). A detailed assessment of seed ornamentation was carried out, considering the ornamentation of the periclinal walls and the type of anticlinal walls [37].
For SEM analysis of leaves and roots from in vitro grown seedlings, transversal sections of fresh material were fixed in FineFIX working solution (Milestone s.r.l., Bergamo, Italy) with 70% ethanol, and left overnight at 4 °C [38]. Sections were then dehydrated for 1 h through graded ethanol series from 70% to 100% at 60 min intervals, and finally dried using a Critical Point Dryer Processor (K850CPD 2M Strumenti S.r.l., Roma, Italy). Specimens were then mounted on stubs, as previously performed on seeds, to carry out micromorphological analyses.

2.4. Data Analysis

Germination data were statistically analyzed by ANOVA followed by Fisher’s probable least-squares difference test, with a cut-off significance at p ≤ 0.001.
Embryo and seed volumes were calculated following the equations reported in [37]:
Embryo volume (EV) = 4/3 πab2
Seed volume (SV) = 2(π/3 r2h)
where a = 0.5 × embryo length (or major axis); b = 0.5 × embryo width (or minor axis); r = 0.5 × seed width (or minor axis); and h = 0.5 × seed length (or major axis).
The morphological data of seeds were analyzed using the R environment [39]. Correlations between seed and embryo volumes were analyzed by means of the cor.test function, using the Spearman’s rank correlation coefficient rho [40,41]. Measures were expressed in μm ± SD.

3. Results

3.1. Seed Germination

Cattleya purpurata seeds germinated on all the tested media. The best medium for asymbiotic germination was 1/2 MS, with a germination percentage of 46.5 ± 6.4%. All the other asymbiotic media yielded lower germination percentages, ranging from 17.1 ± 2.0% (CG0) to 26.3 ± 4.3% (KC). The use of MUT4178 fungal strain of T. calospora resulted in a germination of 18.3 ± 4.0%, statistically comparable with all the variants of CG medium (Table 1).

3.2. Morphology

3.2.1. Seed Morphology

Cattleya purpurata seeds, beige in color, are elongated (Figure 1a) and present a L/W ratio of 5.33 ± 0.62. They showed an average seed length (excluding the suspensor) of 800.47 ± 97.42 μm, an average width of 154.75 ± 22.37 μm, an embryo length of 331.59 ± 48.04 μm, and an embryo width of 127.22 ± 19.98 μm (Table 2). The comparison of seed and embryo volumes showed a significant positive relationship (R = 0.74, p < 0.001) (Supplementary Figure S1). The average suspensor length was 302.52 ± 64.53 μm; no significant relationship was found between suspensor length and both seed and embryo length and either between suspensor length and seed and embryo volumes.
Clarifying treatment with NaOCl allowed us to verify that seed coat was monolayered and that there were no intercellular gaps. Concerning testa, more than five cells were present along the seed longitudinal axis. These cells were elongated; their periclinal cell walls presented verrucosities and granular epicuticular coverings, while their anticlinal walls were occasionally elevated. As shown in Figure 2a,b, the seed coat enveloped the embryo, which showed a relatively long suspensor. Two-three elongated cells connected the embryo body with the portion of suspensor extending beyond the micropyle (Figure 1b, arrow).
The presence of spherical druses (6–8 nm in diameter) within the seed suspensor cells was recorded by both light (Figure 1a,c) and scanning electron microscopy (Figure 2c,d). SEM-EDS analysis of these crystals showed a high calcium peak, typical of the calcium oxalate spectrum (Supplementary Figure S2).

3.2.2. Root Sections

Microscopical analyses highlighted that the structure of roots sampled from C. purpurata seedlings grown on different substrates was qualitatively similar, except for the increased presence of hairs in individuals from CG50 and CG100 media (not shown). Velamen was two to four cells wide (Figure 3a); these cells appeared large, polygonal shaped, and radially elongated, and showed helical-banded wall thickenings (Figure 3b,g). Exodermal cells were moderately large, polygonal-shaped, and ∩-thickened (Figure 3b,d). Short thin-walled passage cells were scattered in the exoderm, near tilosomes of tufted type (Figure 3b, arrows) (according to Pridgeon et al. [42]). In the parenchymatous cortex, the presence of chloroplasts (Figure 3d) and raphides (Figure 3e) was recorded. Cortical cells varied in form and size: elements near to the endodermis were smaller than those of the middle layers (Figure 3a,d); some parenchymatous cells appeared more or less circular, while others were polygonal-shaped (Figure 3a,b,d). As confirmed by means of polarized light (not shown) and by Fluorol Yellow staining, some elements of the cortex presented suberized thickenings in cell walls (Figure 3c, arrows). Endodermis cells were square to tetragonal-shaped; passage cells were visible in correspondence of phloem clusters, while the other endodermis cells appeared O-thickened (Figure 3c). The pericycle presented thin-walled polygonal-shaped cells alternating with protoxylematic cell elements. This layer surrounded the central vascular cylinder characterized by a polyarch actinostele, which showed 10 xylem arches. In the root’s central region, a parenchymal tissue composed by circular cells alternating with lignified elements was present (Figure 3c).
Roots of seedlings obtained from symbiotic cultures showed the presence of mycorrhizal hyphae on the external surface (Figure 3f). The beginning of hyphal coiling was also well visible on the wall thickening of the velamen cells (Figure 3g). Root features are summarized in Table 3.

3.2.3. Leaf Surface and Transversal Sections

The media used for seed germination and seedling development did not lead to structural changes in leaves. Leaf surfaces were composed of mostly rectangular to hexagonal cells and showed a ridged, granular cuticle, 7.0 ± 1.3 µm thick in the abaxial surface and 10.0 ± 1.6 µm in the adaxial one (Figure 4a,b). Tetracytic stomata with C-shaped guard cells were present only in the lower epidermis; the stomatal aperture was parallel to the longitudinal axis of the leaf (Figure 4a). Mean stomatal length was 23.5 ± 2.9 µm, while mean stomatal width was 26.5 ± 2.6 µm. In transversal section, on both sides of the midvein, seven vascular bundles arranged in a row were visible (Figure 4c). The central midvein (Figure 4c,d), positioned near the lower surface, was surrounded by several hypodermal cell layers (not shown). In correspondence of the central midvein, the epidermis was bistratified. The leaf presented a dorsiventral mesophyll at the level of the central midvein and a homogeneous one towards the margins. Parenchyma cells gradually increased in diameter while approaching the central portion, where isodiametric and elongated thick-walled cells were present near the midvein, resembling a palisade parenchyma (Figure 4c). In many cases, we observed vessel elements developed transversely, which connected the small veins (Figure 4e). Vascular collateral bundles showed sclerenchyma caps at both xylem and phloem poles, but predominantly at the phloem one (Figure 4d,e). Little sclerenchyma fiber bundles were present as an abaxial row (not shown), while two clearly distinguishable bundles were positioned at each leaf margin: a little bundle in the margin tip and a larger one more internal (Figure 4c,f). Idioblasts containing raphides were interspersed in the mesophyll (Figure 4f, arrow). Leaf features are summarized in Table 3.
As highlighted by SEM analyses, some mesophyll cell walls were banded (Figure 4g).

4. Discussion

As observed by Gallo et al. [18] and confirmed by our analyses, the seed coat of the studied species consists of only one cell layer. As reminded by the latter authors, the reduced and membranous seed coat of Laeliinae seeds and the air space between the tegument and the embryo is an adaptation related to the aerodynamic properties and to the wettability of seeds [37,43]. While a significant correlation has been found between seed and embryo length, suspensor length was not correlated to seed or embryo size, indicating that suspensor dimension does not influence seed development in C. purpurata.
Although Gallo et al. [18] already described the long multicellular suspensor in C. purpurata and other specimens belonging to the Laeliinae subtribe, the presence of calcium oxalate druses for each cell of the structure had not yet been reported. To the best of our knowledge, this study is the first reporting the occurrence of druses in the suspensor, or more generally, in orchid seeds. In fact, such crystal conglomerates, according to Prychid and Rudall [44], are commonly found in various dicotyledons tissues but are more rarely observed in monocotyledons; concerning family Orchidaceae, druses have been recorded only in vegetative portions of Epidendrae and Dendrobieae [45,46], Arethusae [46], and in the >23% of the Oncidiinae [47].
Lee et al. [48], studying the suspensor of Paphiopedilum delenatii, observed that there was no cuticular material in the cell walls of the structure; considering the morphological traits of the transfer cell, they finally hypothesized that the suspensor was responsible for nutrient uptake for the embryo. Later, the role of embryo suspensor in nutrition has been confirmed [49,50]. In addition, Volk et al. [51] demonstrated that the deposition of druses in idioblasts is a dynamic process and, when Ca availability is reduced, cells could dissolve the crystals metabolizing CaOx to non-toxic compounds. According to these authors and considering our observations, it is possible that the suspensor possesses storage potential and, while providing a channel for nutrients conduction to embryo, could store the excess of calcium coming from the environment or could receive it as a byproduct of seed metabolism. Calcium oxalate, on the other hand, has many functional roles also for fungi, such as metal detoxification or increasing plant susceptibility to fungal infection, acting as an electron donor in lignocellulose degradation [52] and in the reduction of certain metals [53]. Oxalate, indeed, plays a unique role in lignocellulose degradation by basidiomycetes, acting as a low molecular mass agent initiating decay and as a potential electron donor for lignin-peroxidase catalyzed reduction [54,55,56]. This is particularly interesting because fungal colonization of orchid seeds by orchid mycorrhizal fungi (belonging to the Basidiomycota) occurs through the suspensor [57,58,59,60]. It is tempting to hypothesize that the druses have evolutionarily assumed the role of ready-to-use oxalate reserves available to the symbiont fungi to favor the degradation of the lignocellulose present in the seed coat [61] and their settlement as symbionts. It should be remembered that, in mycorrhizal fungi, the energy balance is very important [22] and even more so in orchid mycorrhizal fungi, where the debate in the scientific community is still ongoing [22,62,63]. Possibly supporting this hypothesis, Miura et al. [64] found that the presence of seed coat enhances seed germination with symbiotic fungi and protects the embryo against the attack of non-symbiotic fungi by restricting the invasion of their fungal hyphae. Indeed, the seed coat is a barrier against fungi that do not possess enzymes capable of degrading lignocellulose, making a sort of selection at the entrance.
However, as the druses deposition was recorded starting from the first two cells after the elongated pair and all along the suspensor (see Figure 3a,b), we cannot exclude that its detachment from the developing embryo in the early stages of germination might be a fast way to remove the excess of calcium oxalate. This hypothesis agrees to that discussed by Paiva [65], who concluded that the formation of CaOx crystals in portions that will be discarded allows the excretion of calcium, because plants lack excretory systems.
Germination was successful on all the media tested, but 1/2 MS was the best and is therefore suggested for C. purpurata propagation. Germination occurred also by using the fungal strain MUT4178 of Tulasnella calospora but with a lower percentage if compared to the above-mentioned asymbiotic medium. Almeida et al. [26] indicated Tulasnellaceae (including T. calospora) as the main possible fungal symbionts for this orchid group; however, our results, which report the first attempt of symbiotic germination for C. purpurata (to the best of our knowledge) may indicate that the fungal strain used, isolated from an European terrestrial orchid, might not be the most appropriate or the dominant symbiont for this species, even if we demonstrated its colonization of roots (see also Adamo et al. [27]).
The subsequent development of seedlings grown in vitro allowed characterization of their morphology. According to the literature, this is the first study providing morphological information regarding in vitro seedlings of C. purpurata, because Gallo et al. [18] worked on the same species but in earlier stages of protocorm development, while Silva Júnior et al. [17] compared the anatomy of roots and leaves from plants treated with different urea concentrations.
We observed idioblasts containing raphides in both root and leaf tissues, adding information regarding their presence in the early development stages of seedlings. The occurrence, distribution, and morphology of idioblasts containing raphides have been reported by various authors who studied the vegetative tissues of most of the analyzed orchid subtribes [66] (and references therein). Stern and Carlsward [67] carried out a comparative study concerning vegetative portions of members from Laeliinae, and found that crystalliferous idioblasts, circular in transverse section and saccate in the longitudinal one, are present ubiquitously in the mesophyll of all the examined taxa. In general, the role of raphides for plant tissues also needs to be clarified. As recently revised by Paiva [65], various hypotheses about the functions of raphides in plant tissues have been indeed formulated; they could help in regulating calcium levels [51] or constitute a CO2 source for photosynthesis in some species [68]. Tulyananda and Nilsen [69] stated that idioblasts spread in thin leaves of epiphytic species (in this case, Rhododendron sp.) act as buffering agents that significantly affect leaf-lamina water relations. As previously proposed by several authors and recently revised by Konno et al. [70], raphides could play a defensive role against herbivory.
Some of the anatomical characters observed in the roots and leaves of the studied species are typical to those of epiphytic orchid habit.
Root presented a 2–3 layered velamen, showing helical cell wall thickenings. Such a restricted number of velamen layers is characteristic of species belonging to relatively humid habitats [71]. Velamen avoids the loss of moisture from roots, speeds up water absorption, and provides protection against mechanical stresses and ultraviolet radiations [72,73]. On the other hand, helical thickenings in the velamen cells have the function to improve the stability and efficiency of this tissue for water absorption by the root and its retention in dry conditions in epiphytic orchids [74]. Passage cells constitute a channel for the selective transit of nutrients and water, and for the entrance of mychorrhizal fungi [71,75,76]. Tilosomes, branched lignified wall ingrowths on the internal periclinal wall of the endovelamen cells, are typically positioned near passage cells [77,78]. These structures, according to Kedrovski and Sajo [78], increase symplastic connections and improve water and solutes transport between external and internal environments in young tissues, while they steer solutes to passage cells in mature tissues. Stern and Carlsward [67] stated that there are no tilosomes in Cattleya but annotated their occurrence in other species that have been moved in this genus in times after their work, i.e., Sophronitis sincorana (now C. sincorana) and Laelia anceps (now C. anceps). Our observation confirms the fact that tilosomes are also present in Cattleya genus.
The monolayered exodermis with large elements with ∩-thickened cell walls is also typical of epiphytic orchids. This structure prevents transpiration and water loss from the cortex [71].
Taken together, the characteristics of exodermis, the number of velamen layers, the occurrence and orientation of thickenings in velamen cell walls, and the presence of tilosomes possess taxonomical value according to Porembsky and Barthlott [77]. To classify orchid roots, the latter authors indeed considered combinations of the aforementioned characters, proposing 12 different syndromes; the complex of features showed by our study species resembles that of Vanda-type.
A high presence of chloroplasts was recorded in the cortex. This aspect is well known for Laeliinae [67] and in general for epiphytic orchids; many species have evolved photosynthetic roots to increase photosynthetic areas and consequently carbon gain [72,79,80].
The variable shape and the presence of thickened birefringent cell walls of cortex elements agree with what has been reported for other Laeliinae members by Stern and Carlsward [67]. Additionally, both endodermis and pericycle cells show characteristics already described by the latter authors (similar in dimension and O-thickened); however, contrary to what has been observed in general for Laeliinae, we recognized O-thickenings in correspondence of xylem rays instead of phloem ones, and protoxylematic elements in the pericycle. Lignin deposition in other elements of the central cylinder and endodermal cell wall thickenings may play similar functions to those of velamen and exodermis (prevention of water loss) and constitute another adaptative trait to tropical habitat conditions [71].
The number of xylem arches (10) falls in the range of 7–24, reported for this group of orchids [67]. Gallo et al. [18] recorded a triarch-tetrarch actynostele in developing protocorms, but it should be remembered that the organization of the vascular system undergoes changes during plant development [81].
Additionally, leaf characteristics are in line with the ecological adaptations of C. purpurata to a tropical environment. The roughness and thickness of C. purpurata leaf cuticles are consistent with characters and data previously annotated for Laeliinae [67]. The cuticle, relatively thick if compared to other orchid species [82], plays an ecological role in transpiration reduction and in drought resistance [83,84,85]. Similar considerations could be drawn for stomata dimensions, as small stomata are known to be quicker to close and then are more tolerant to dry conditions [84].
The stomatal apparatus is tetracytic, as noted in most Laeliinae; however, while a reniform shape was described for all the other taxa [66,67], the C-shaped guard cells that we observed were previously reported only for Cattleya sincorana (syn. Sophronitis sincorana). This latter record can be useful to corroborate taxonomical information regarding the studied species.
The data regarding the discontinuous hypodermis, the homogeneous mesophyll, and the dorsiventral one in correspondence of the central rib, together with the characteristics of vascular system, agree to what is generally known for Laeliinae [67]. On the other hand, the presence of transversally developed elements, which constitute anastomoses between veins in the mesophyll, was less frequently annotated in the subtribe. It has been proposed that they provide mechanical stability and discourage herbivory [86]. The occurrence of transverse veins in the mesophyll of C. purpurata is in line with previous findings for the genus Cattleya [87].

5. Conclusions

In conclusion, we compared germination on different media and, for the first time, attempted symbiotic germination for Cattleya purpurata, demonstrating the potential use of Tulasnellaceae, which otherwise need to be refined, looking for the best symbiotic fungal partner because germination percentage was lower than that obtained on some asymbiotic media. Furthermore, we characterized its seed and seedling morphology, providing new insights into the knowledge of this endangered species. Seedling morphology was comparable with other congeneric species, showing typical characteristics of epiphytic orchids such as root velamen with 2–3 cells layers. We confirmed the presence of tilosomes in roots in this orchid genus and observed stomata with C-shaped guard cells in leaves, which are unusually found in Cattleya species. Interestingly, we pointed out the presence of calcium oxalate crystals, both in idioblasts as raphides (in roots and leaves) and in the seed suspensor as druzes. It would be intriguing, in the future, to see if other orchid species actually accumulate these crystals in the suspensor and if they have a nutritional/functional role in the orchid symbiosis.

Supplementary Materials

The following are available online at https://www.mdpi.com/article/10.3390/horticulturae7110480/s1, Figure S1: Correlation between the volume of the embryo and the seed analyzed by means of the cor.test( ) function using the Spearman’s rank correlation coefficient rho, Figure S2: Main elements present in crystals determined by SEM-EDS spectrum. The analysis showed a chemical composition typically obtained for calcium oxalate, with carbon (C), oxygen (O) and calcium (Ca) peaks.

Author Contributions

Conceptualization, J.C. and M.B.; methodology, J.C., M.B., A.C. and L.C.; software, J.C., M.B. and M.A.; validation, J.C., M.B. and L.C.; formal analysis, J.C. and M.B.; investigation, J.C. and M.B.; resources, J.C., L.C. and A.G.; data curation, J.C. and M.B.; writing—original draft preparation, J.C. and M.B.; writing—review and editing, M.B., J.C., M.A., A.G., A.C. and L.C.; visualization, J.C., M.B., M.A., A.C. and L.C.; supervision, L.C. All authors have read and agreed to the published version of the manuscript.

Funding

This research received no external funding.

Institutional Review Board Statement

Not applicable.

Informed Consent Statement

Not applicable.

Data Availability Statement

Not applicable.

Acknowledgments

The experimental work for this study has been performed within the framework of the doctoral research projects of J. Calevo (PhD School in Biology and Applied Biotechnologies, University of Turin) and M. Bazzicalupo (PhD School in Science and Technology for the Environment and Territory, University of Genoa), both funded by the Ministry of Education and Research (MIUR). M. Adamo was supported by a grant from CMIRA (Coopération et Mobilité Internationales Rhône-Alpes) program of region Rhône-Alpes, France. We thank Laura Negretti for SEM images.

Conflicts of Interest

The authors declare no conflict of interest.
