Bioengineering 2017, 4(1), 9; doi:10.3390/bioengineering4010009

Multivariate Curve Resolution and Carbon Balance Constraint to Unravel FTIR Spectra from Fed-Batch Fermentation Samples

1
AG Biophysik und Medizinische Physik, Technische Universität Kaiserslautern, Kaiserslautern 67663, Germany
2
Fachbereich Bioverfahrenstechnik, Hochschule Trier, Umwelt-Campus Birkenfeld, Birkenfeld 55761, Germany
3
Fachbereich Angewandte Informatik, Hochschule Trier, Umwelt-Campus Birkenfeld, Birkenfeld 55761, Germany
*
Author to whom correspondence should be addressed.
Academic Editor: Christoph Herwig
Received: 30 October 2016 / Revised: 20 December 2016 / Accepted: 19 January 2017 / Published: 25 January 2017
(This article belongs to the Special Issue Hybrid Modelling and Multi-Parametric Control of Bioprocesses)
View Full-Text   |   Download PDF [5178 KB, uploaded 25 January 2017]   |

Abstract

The current work investigates the capability of a tailored multivariate curve resolution–alternating least squares (MCR-ALS) algorithm to analyse glucose, phosphate, ammonium and acetate dynamics simultaneously in an E. coli BL21 fed-batch fermentation. The high-cell-density (HCDC) process is monitored by ex situ online attenuated total reflection (ATR) Fourier transform infrared (FTIR) spectroscopy and several in situ online process sensors. This approach efficiently utilises automatically generated process data to reduce the time and cost consuming reference measurement effort for multivariate calibration. To determine metabolite concentrations with accuracies between ±0.19 and ±0.96·gL−l, the presented utilisation needs primarily—besides online sensor measurements—single FTIR measurements for each of the components of interest. The ambiguities in alternating least squares solutions for concentration estimation are reduced by the insertion of analytical process knowledge primarily in the form of elementary carbon mass balances. Thus, in this way, the established idea of mass balance constraints in MCR combines with the consistency check of measured data by carbon balances, as commonly applied in bioprocess engineering. The constraints are calculated based on online process data and theoretical assumptions. This increased calculation effort is able to replace, to a large extent, the need for manually conducted quantitative chemical analysis, leads to good estimations of concentration profiles and a better process understanding. View Full-Text
Keywords: multivariate curve resolution; E. coli; fed-batch; fermentation; carbon mass balance constraint; soft constraints; alternating least squares; hybrid modelling multivariate curve resolution; E. coli; fed-batch; fermentation; carbon mass balance constraint; soft constraints; alternating least squares; hybrid modelling
Figures

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Vier, D.; Wambach, S.; Schünemann, V.; Gollmer, K.-U. Multivariate Curve Resolution and Carbon Balance Constraint to Unravel FTIR Spectra from Fed-Batch Fermentation Samples. Bioengineering 2017, 4, 9.
