Processes 2014, 2(1), 180-199; doi:10.3390/pr2010180

Analysis of Multi-Loop Control Structures of Dividing-Wall Distillation Columns Using a Fundamental Model

1 Department of Biomedical Engineering, Department of Chemical & Biological Engineering, Rensselaer Polytechnic Institute, Troy, NY 12180-3590, USA 2 Departamento de Ingeniería Química, Instituto Tecnológico de Celaya, Ave. Tecnológico y García Cubas S/N, Celaya 38010, Gto., Mexico
* Author to whom correspondence should be addressed.
Received: 11 November 2013 / Revised: 23 January 2014 / Accepted: 11 February 2014 / Published: 24 February 2014
View Full-Text   |   Download PDF [1222 KB, uploaded 24 February 2014]   |   Browse Figures


Dividing-wall columns (DWCs) have significant potential as energy-efficient processes for the separation of multicomponent mixtures. However, in addition to an efficient steady state design, dynamics and control also play a major part for the success of a technology. This is especially so for complex distillation systems. This paper investigates the dynamics of a dividing wall column used for the separation of ternary mixtures. A detailed dynamic first principles-based model of the column I s developed in gPROMS. The model is used to generate data used for control loop pairing via the Relative Gain Array (RGA), and controller parameters are found by using Internal Model Control (IMC) tuning. The best control structures for DWC systems, involving four different ternary mixtures, and two different feed compositions for each mixture, are investigated.
Keywords: dividing-wall column; distillation; petlyuk; IMC dividing-wall column; distillation; petlyuk; IMC
This is an open access article distributed under the Creative Commons Attribution License (CC BY) which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.

Share & Cite This Article

Further Mendeley | CiteULike
Export to BibTeX |
MDPI and ACS Style

Tututi-Avila, S.; Jiménez-Gutiérrez, A.; Hahn, J. Analysis of Multi-Loop Control Structures of Dividing-Wall Distillation Columns Using a Fundamental Model. Processes 2014, 2, 180-199.
