Coatings 2017, 7(1), 3; doi:10.3390/coatings7010003

Study of a Particle Based Films Cure Process by High-Frequency Eddy Current Spectroscopy

1
The Institute of Electronic Packaging Technology, Faculty of Electrical and Computer Engineering, Technische Universität Dresden, Mommsenstrasse 15, Dresden 01069, Germany
2
Fraunhofer Institute for Ceramic Technologies and Systems, Maria-Reiche Str. 22, Dresden 01109, Germany
3
Microelectronics Department, Faculty of Electronics, National Technical University of Ukraine “Igor Sikorsky Kyiv Polytechnic Institute”, Peremohy Ave 37, Kyiv 03056, Ukraine
*
Author to whom correspondence should be addressed.
Academic Editor: Günter Motz
Received: 21 September 2016 / Revised: 14 December 2016 / Accepted: 19 December 2016 / Published: 28 December 2016
(This article belongs to the Special Issue Advances in Coatings Characterization)
View Full-Text   |   Download PDF [8287 KB, uploaded 28 December 2016]   |

Abstract

Particle-based films are today an important part of various designs and they are implemented in structures as conductive parts, i.e., conductive paste printing in the manufacture of Li-ion batteries, solar cells or resistive paste printing in IC. Recently, particle based films were also implemented in the 3D printing technique, and are particularly important for use in aircraft, wind power, and the automotive industry when incorporated onto the surface of composite structures for protection against damages caused by a lightning strike. A crucial issue for the lightning protection area is to realize films with high homogeneity of electrical resistance where an in-situ noninvasive method has to be elaborated for quality monitoring to avoid undesirable financial and time costs. In this work the drying process of particle based films was investigated by high-frequency eddy current (HFEC) spectroscopy in order to work out an automated in-situ quality monitoring method with a focus on the electrical resistance of the films. Different types of particle based films deposited on dielectric and carbon fiber reinforced plastic substrates were investigated in the present study and results show that the HFEC method offers a good opportunity to monitor the overall drying process of particle based films. Based on that, an algorithm was developed, allowing prediction of the final electrical resistance of the particle based films throughout the drying process, and was successfully implemented in a prototype system based on the EddyCus® HFEC device platform presented in this work. This prototype is the first solution for a portable system allowing HFEC measurement on huge and uneven surfaces. View Full-Text
Keywords: EddyCus®; eddy wet; eddy current; HFEC; particle based films; in-situ quality control; noninvasive method; composite material; drying process EddyCus®; eddy wet; eddy current; HFEC; particle based films; in-situ quality control; noninvasive method; composite material; drying process
