Open AccessArticle
J. Funct. Biomater. 2018, 9(3), 40; https://doi.org/10.3390/jfb9030040

Genipin-Enhanced Fibrin Hydrogel and Novel Silk for Intervertebral Disc Repair in a Loaded Bovine Organ Culture Model

1
Tissue & Organ Mechano Biology, Institute for Surgical Technology and Biomechanics, University of Bern, 3012 Bern, Switzerland
2
Laboratory of Molecular and Cellular Screening Processes, Centre of Biotechnology of Sfax, University of Sfax, Sfax 3018, Tunisia
3
Institute of Textile Machinery and High Performance Material Technology, TU Dresden, 01062 Dresden, Germany
4
Department of Orthopaedic Surgery and Traumatology, Spine Unit, Insel Hospital, Bern University Hospital, Bern 3010, Switzerland
*
Author to whom correspondence should be addressed.
Received: 3 June 2018 / Revised: 20 June 2018 / Accepted: 20 June 2018 / Published: 24 June 2018
(This article belongs to the Special Issue Biomaterials for Spinal Applications)
Full-Text   |   PDF [3910 KB, uploaded 25 June 2018]   |

Abstract

(1) Background: Intervertebral disc (IVD) repair represents a major challenge. Using functionalised biomaterials such as silk combined with enforced hydrogels might be a promising approach for disc repair. We aimed to test an IVD repair approach by combining a genipin-enhanced fibrin hydrogel with an engineered silk scaffold under complex load, after inducing an injury in a bovine whole organ IVD culture; (2) Methods: Bovine coccygeal IVDs were isolated from ~1-year-old animals within four hours post-mortem. Then, an injury in the annulus fibrosus was induced by a 2 mm biopsy punch. The repair approach consisted of genipin-enhanced fibrin hydrogel that was used to fill up the cavity. To seal the injury, a Good Manufacturing Practise (GMP)-compliant engineered silk fleece-membrane composite was applied and secured by the cross-linked hydrogel. Then, IVDs were exposed to one of three loading conditions: no load, static load and complex load in a two-degree-of-freedom bioreactor for 14 days. Followed by assessing DNA and matrix content, qPCR and histology, the injured discs were compared to an uninjured control IVD that underwent the same loading profiles. In addition, the genipin-enhanced fibrin hydrogel was further investigated with respect to cytotoxicity on human stem cells, annulus fibrosus, and nucleus pulposus cells; (3) Results: The repair was successful as no herniation could be detected for any of the three loading conditions. Disc height was not recovered by the repair DNA and matrix contents were comparable to a healthy, untreated control disc. Genipin resulted being cytotoxic in the in vitro test but did not show adverse effects when used for the organ culture model; (4) Conclusions: The current study indicated that the combination of the two biomaterials, i.e., genipin-enhanced fibrin hydrogel and an engineered silk scaffold, was a promising approach for IVD repair. Furthermore, genipin-enhanced fibrin hydrogel was not suitable for cell cultures; however, it was highly applicable as a filler material. View Full-Text
Keywords: organ culture; bioreactor; intervertebral disc; mechanical loading; genipin; fibrin; silk; repair; fibre-reinforced hydrogel; qPCR; cell activity; histology organ culture; bioreactor; intervertebral disc; mechanical loading; genipin; fibrin; silk; repair; fibre-reinforced hydrogel; qPCR; cell activity; histology
Figures

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Frauchiger, D.A.; May, R.D.; Bakirci, E.; Tekari, A.; Chan, S.C.W.; Wöltje, M.; Benneker, L.M.; Gantenbein, B. Genipin-Enhanced Fibrin Hydrogel and Novel Silk for Intervertebral Disc Repair in a Loaded Bovine Organ Culture Model. J. Funct. Biomater. 2018, 9, 40.
