Open AccessArticle
Water 2018, 10(8), 1048; https://doi.org/10.3390/w10081048

The Stability of Tailings Dams under Dry-Wet Cycles: A Case Study in Luonan, China

1
Key Laboratory of Mine Geological Hazards Mechanism and Control, Shaanxi Institute of Geo-Environment Monitoring, Xi’an 710054, China
2
State Key Laboratory of Continental Dynamics, Department of Geology, Northwest University, Xi’an 710069, China
3
Department of Geology and Geophysics, Texas A&M University, College Station, TX 77840, USA
*
Authors to whom correspondence should be addressed.
Received: 12 July 2018 / Revised: 2 August 2018 / Accepted: 3 August 2018 / Published: 7 August 2018
(This article belongs to the Special Issue Water-Induced Landslides: Prediction and Control)
View Full-Text   |   Download PDF [4013 KB, uploaded 8 August 2018]   |

Abstract

Instability of tailings dams may result in loss of life and property and serious environmental pollution. The position of the tailings dam’s phreatic line varies due to continuously changing factors such as rainfall infiltration and discharge of tailings recycling water. Consequently, tailings dams undergo dry-wet (DW) cycles, accompanied by the appearance of a hydro-fluctuation belt. With dynamic development of the physical and chemical properties of tailings sand in the hydro-fluctuation belt, the stability of tailings dams is uncertain. In this study, direct shear tests were performed on the tailings sand collected from a tailings dam in Luonan, through which the shear strength parameters of tailings sand with DW cycles were obtained. Then, a method that efficiently calculates the phreatic line of the tailings dam under DW cycles was proposed. In addition, based on laboratory tests and the proposed phreatic line calculation method, we used a finite element program to evaluate the stability of the tailings dam that experienced different DW cycles. The calculated results showed that: (i) the damage effects of DW cycles gradually weakens as the number of DW cycles increases. (ii) With the increasing of DW cycles, the maximum displacement of the tailings dam increases from 0.5 mm to 22 mm, and the area of maximum displacement expanded mainly at the toe of the tailings dam and at the front edge of the hydro-fluctuation belt. (iii) The tailings dam safety factor decreases continuously with increasing DW cycles. This study may provide a novel method for analyzing the stability of tailings dams under different DW cycles as well as an important reference for improving tailings dam stability. View Full-Text
Keywords: dry-wet (DW) cycle; tailings dam; hydro-fluctuation belt; phreatic line; stability dry-wet (DW) cycle; tailings dam; hydro-fluctuation belt; phreatic line; stability
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
