Materials 2016, 9(4), 253; doi:10.3390/ma9040253

Fabrication of Bendable Circuits on a Polydimethylsiloxane (PDMS) Surface by Inkjet Printing Semi-Wrapped Structures

1
School of Chemistry and Environment, Beihang University, Beijing 100191, China
2
Key Laboratory of Green Printing, Institute of Chemistry, Chinese Academy of Sciences, Beijing Engineering Research Center of Nanomaterials for Green Printing Technology, Beijing National Laboratory for Molecular Sciences, Beijing 100190, China
*
Author to whom correspondence should be addressed.
Academic Editor: Jordi Faraudo
Received: 14 February 2016 / Revised: 18 March 2016 / Accepted: 21 March 2016 / Published: 30 March 2016
(This article belongs to the Special Issue Surface Forces and Thin Liquid Films)
View Full-Text   |   Download PDF [3724 KB, uploaded 30 March 2016]   |

Abstract

In this work, an effective method was developed to fabricate bendable circuits on a polydimethylsiloxane (PDMS) surface by inkjet printing semi-wrapped structures. It is demonstrated that the precured PDMS liquid film could influence the depositing morphology of coalesced silver precursor inkjet droplets. Accordingly, continuous and uniform lines with a semi-wrapped structure were fabricated on the PDMS surface. When the printed silver precursor was reduced to Ag nanoparticles, the fabricated conductive film exhibited good transparency and high bendability. This work presented a facile way to fabricate flexible patterns on a PDMS surface without any complicated modification or special equipment. Meanwhile, an in situ hydrazine reduction of Ag has been reported using the vapor phase method in the fabricating process. View Full-Text
Keywords: inkjet droplet; precured PDMS; depositing morphology; bendable circuit inkjet droplet; precured PDMS; depositing morphology; bendable circuit
