Open AccessArticle
Energies 2015, 8(6), 5538-5554; doi:10.3390/en8065538

Metamodel for Efficient Estimation of Capacity-Fade Uncertainty in Li-Ion Batteries for Electric Vehicles

1
School of Aerospace and Mechanical Engineering, Korea Aerospace University, Goyang 412-791, Korea
2
Research and Development Division, Hyundai Motor Company, Hwaseong 445-706, Korea
*
Author to whom correspondence should be addressed.
Academic Editor: Paul Stewart
Received: 4 April 2015 / Revised: 26 May 2015 / Accepted: 27 May 2015 / Published: 9 June 2015
(This article belongs to the Special Issue Electrical Power and Energy Systems for Transportation Applications)
View Full-Text   |   Download PDF [1340 KB, uploaded 9 June 2015]   |

Abstract

This paper presents an efficient method for estimating capacity-fade uncertainty in lithium-ion batteries (LIBs) in order to integrate them into the battery-management system (BMS) of electric vehicles, which requires simple and inexpensive computation for successful application. The study uses the pseudo-two-dimensional (P2D) electrochemical model, which simulates the battery state by solving a system of coupled nonlinear partial differential equations (PDEs). The model parameters that are responsible for electrode degradation are identified and estimated, based on battery data obtained from the charge cycles. The Bayesian approach, with parameters estimated by probability distributions, is employed to account for uncertainties arising in the model and battery data. The Markov Chain Monte Carlo (MCMC) technique is used to draw samples from the distributions. The complex computations that solve a PDE system for each sample are avoided by employing a polynomial-based metamodel. As a result, the computational cost is reduced from 5.5 h to a few seconds, enabling the integration of the method into the vehicle BMS. Using this approach, the conservative bound of capacity fade can be determined for the vehicle in service, which represents the safety margin reflecting the uncertainty. View Full-Text
Keywords: lithium-ion battery; capacity fade; electrochemical model; battery management system; electric vehicles; uncertainty estimation; Markov Chain Monte Carlo; metamodel lithium-ion battery; capacity fade; electrochemical model; battery management system; electric vehicles; uncertainty estimation; Markov Chain Monte Carlo; metamodel
This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Lee, J.; Sung, W.; Choi, J.-H. Metamodel for Efficient Estimation of Capacity-Fade Uncertainty in Li-Ion Batteries for Electric Vehicles. Energies 2015, 8, 5538-5554.
