Performance Evaluation of IEEE 802.11ah Networks With High-Throughput Bidirectional Traffic
Previous Article in Journal
Single-Photon Tracking for High-Speed Vision
Article Menu
Issue 2 (February) cover image

Export Article

Open AccessArticle
Sensors 2018, 18(2), 324; https://doi.org/10.3390/s18020324

An Efficient Direct Position Determination Method for Multiple Strictly Noncircular Sources

1,2
,
1,2,* and 1,2
1
National Digital Switching System Engineering and Technology Research Center, Zhengzhou 450002, China
2
Zhengzhou Information Science and Technology Institute, Zhengzhou 450002, China
*
Author to whom correspondence should be addressed.
Received: 5 November 2017 / Revised: 6 December 2017 / Accepted: 19 December 2017 / Published: 23 January 2018
(This article belongs to the Section Physical Sensors)
View Full-Text   |   Download PDF [1803 KB, uploaded 26 January 2018]   |

Abstract

This paper focuses on the localization methods for multiple sources received by widely separated arrays. The conventional two-step methods extract measurement parameters and then estimate the positions from them. In the contrast to the conventional two-step methods, direct position determination (DPD) localizes transmitters directly from original sensor outputs without estimating intermediate parameters, resulting in higher location accuracy and avoiding the data association. Existing subspace data fusion (SDF)-based DPD developed in the frequency domain is computationally attractive in the presence of multiple transmitters, whereas it does not use special properties of signals. This paper proposes an improved SDF-based DPD algorithm for strictly noncircular sources. We first derive the property of strictly noncircular signals in the frequency domain. On this basis, the observed frequency-domain vectors at all arrays are concatenated and extended by exploiting the noncircular property, producing extended noise subspaces. Fusing the extended noise subspaces of all frequency components and then performing a unitary transformation, we obtain a cost function for each source location, which is formulated as the smallest eigenvalue of a real-valued matrix. To avoid the exhaustive grid search and solve this nonlinear function efficiently, we devise a Newton-type iterative method using matrix Eigen-perturbation theory. Simulation results demonstrate that the proposed DPD using Newton-type iteration substantially reduces the running time, and its performance is superior to other localization methods for both near-field and far-field noncircular sources. View Full-Text
Keywords: array signal processing; passive localization; direct position determination (DPD); noncircular source; frequency domain; extended subspace data fusion (SDF); Newton-type iteration array signal processing; passive localization; direct position determination (DPD); noncircular source; frequency domain; extended subspace data fusion (SDF); Newton-type iteration
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Share & Cite This Article

MDPI and ACS Style

Yin, J.; Wang, D.; Wu, Y. An Efficient Direct Position Determination Method for Multiple Strictly Noncircular Sources. Sensors 2018, 18, 324.
