Sensors 2017, 17(7), 1497; doi:10.3390/s17071497

A Multi-Resolution Mode CMOS Image Sensor with a Novel Two-Step Single-Slope ADC for Intelligent Surveillance Systems

1
Department of Semiconductor Science, Dongguk University-Seoul, Seoul 04620, Korea
2
Department of Information and Telecommunication Engineering, Dongguk University-Seoul, Seoul 04620, Korea
*
Author to whom correspondence should be addressed.
Received: 9 May 2017 / Revised: 8 June 2017 / Accepted: 24 June 2017 / Published: 25 June 2017
(This article belongs to the Special Issue Image Sensors)
View Full-Text   |   Download PDF [3534 KB, uploaded 26 June 2017]   |

Abstract

In this paper, we present a multi-resolution mode CMOS image sensor (CIS) for intelligent surveillance system (ISS) applications. A low column fixed-pattern noise (CFPN) comparator is proposed in 8-bit two-step single-slope analog-to-digital converter (TSSS ADC) for the CIS that supports normal, 1/2, 1/4, 1/8, 1/16, 1/32, and 1/64 mode of pixel resolution. We show that the scaled-resolution images enable CIS to reduce total power consumption while images hold steady without events. A prototype sensor of 176 × 144 pixels has been fabricated with a 0.18 μm 1-poly 4-metal CMOS process. The area of 4-shared 4T-active pixel sensor (APS) is 4.4 μm × 4.4 μm and the total chip size is 2.35 mm × 2.35 mm. The maximum power consumption is 10 mW (with full resolution) with supply voltages of 3.3 V (analog) and 1.8 V (digital) and 14 frame/s of frame rates. View Full-Text
Keywords: CMOS image sensor; fixed pattern noise; intelligent surveillance system (ISS); low power consumption; multi-mode pixel resolution; two-step single-slope ADC CMOS image sensor; fixed pattern noise; intelligent surveillance system (ISS); low power consumption; multi-mode pixel resolution; two-step single-slope ADC
Figures

Figure 1
