Sensors 2017, 17(6), 1448; doi:10.3390/s17061448

On the Application of Image Processing Methods for Bubble Recognition to the Study of Subcooled Flow Boiling of Water in Rectangular Channels

School of Industrial Engineering, University of Vigo, Lagoas-Marcosende, Vigo 36310, Spain
*
Author to whom correspondence should be addressed.
Received: 15 May 2017 / Revised: 15 June 2017 / Accepted: 16 June 2017 / Published: 20 June 2017
(This article belongs to the Section Physical Sensors)
View Full-Text   |   Download PDF [5768 KB, uploaded 20 June 2017]   |

Abstract

This work introduces the use of machine vision in the massive bubble recognition process, which supports the validation of boiling models involving bubble dynamics, as well as nucleation frequency, active site density and size of the bubbles. The two algorithms presented are meant to be run employing quite standard images of the bubbling process, recorded in general-purpose boiling facilities. The recognition routines are easily adaptable to other facilities if a minimum number of precautions are taken in the setup and in the treatment of the information. Both the side and front projections of subcooled flow-boiling phenomenon over a plain plate are covered. Once all of the intended bubbles have been located in space and time, the proper post-process of the recorded data become capable of tracking each of the recognized bubbles, sketching their trajectories and size evolution, locating the nucleation sites, computing their diameters, and so on. After validating the algorithm’s output against the human eye and data from other researchers, machine vision systems have been demonstrated to be a very valuable option to successfully perform the recognition process, even though the optical analysis of bubbles has not been set as the main goal of the experimental facility. View Full-Text
Keywords: machine vision; flow visualization; bubble recognition; bubble tracking; subcooled flow boiling machine vision; flow visualization; bubble recognition; bubble tracking; subcooled flow boiling
