Sensors 2017, 17(6), 1197; doi:10.3390/s17061197

Human Thalamic Somatosensory Nucleus (Ventral Caudal, Vc) as a Locus for Stimulation by INPUTS from Tactile, Noxious and Thermal Sensors on an Active Prosthesis

1
Department of Neurosurgery, Johns Hopkins University, Baltimore, MD 21287, USA
2
Departments of Neurology and Cognitive Science, Johns Hopkins University, Baltimore, MD 21287, USA
3
Department of Pain Translational Symptom Science, School of Nursing, and Department of Anesthesiology, School of Medicine, University of Maryland, Baltimore, MD 20742, USA
4
Department of Psychiatry and Behavioral Sciences, Johns Hopkins University, Baltimore, MD 21287, USA
5
Department of Anesthesiology and Critical Care Medicine, M.D. Anderson Hospital, Houston, TX 77054, USA
*
Author to whom correspondence should be addressed.
Academic Editor: Maurizio Valle
Received: 31 March 2017 / Revised: 5 May 2017 / Accepted: 16 May 2017 / Published: 24 May 2017
(This article belongs to the Special Issue Tactile Sensors and Sensing)
View Full-Text   |   Download PDF [1404 KB, uploaded 24 May 2017]   |

Abstract

The forebrain somatic sensory locus for input from sensors on the surface of an active prosthesis is an important component of the Brain Machine Interface. We now review the neuronal responses to controlled cutaneous stimuli and the sensations produced by Threshold Stimulation at Microampere current levels (TMIS) in such a locus, the human thalamic Ventral Caudal nucleus (Vc). The responses of these neurons to tactile stimuli mirror those for the corresponding class of tactile mechanoreceptor fiber in the peripheral nerve, and TMIS can evoke sensations like those produced by the stimuli that optimally activate each class. These neuronal responses show a somatotopic arrangement from lateral to medial in the sequence: leg, arm, face and intraoral structures. TMIS evoked sensations show a much more detailed organization into anterior posteriorly oriented rods, approximately 300 microns diameter, that represent smaller parts of the body, such as parts of individual digits. Neurons responding to painful and thermal stimuli are most dense around the posterior inferior border of Vc, and TMIS evoked pain sensations occur in one of two patterns: (i) pain evoked regardless of the frequency or number of spikes in a burst of TMIS; and (ii) the description and intensity of the sensation changes with increasing frequencies and numbers. In patients with major injuries leading to loss of somatic sensory input, TMIS often evokes sensations in the representation of parts of the body with loss of sensory input, e.g., the phantom after amputation. Some patients with these injuries have ongoing pain and pain evoked by TMIS of the representation in those parts of the body. Therefore, thalamic TMIS may produce useful patterned somatotopic feedback to the CNS from sensors on an active prosthesis that is sometimes complicated by TMIS evoked pain in the representation of those parts of the body. View Full-Text
Keywords: sensor; active prosthesis; thalamus; mechanoreception; nociception; neuron; microstimulation sensor; active prosthesis; thalamus; mechanoreception; nociception; neuron; microstimulation
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
