Open AccessArticle
Sensors 2016, 16(6), 900; doi:10.3390/s16060900

A Thermal Performance Analysis and Comparison of Fiber Coils with the D-CYL Winding and QAD Winding Methods

College of Automation, Harbin Engineering University, Harbin 150001, Heilongjiang, China
*
Author to whom correspondence should be addressed.
Academic Editor: Vittorio M. N. Passaro
Received: 28 April 2016 / Revised: 1 June 2016 / Accepted: 2 June 2016 / Published: 16 June 2016
(This article belongs to the Section Physical Sensors)
View Full-Text   |   Download PDF [2565 KB, uploaded 16 June 2016]   |

Abstract

The thermal performance under variable temperature conditions of fiber coils with double-cylinder (D-CYL) and quadrupolar (QAD) winding methods is comparatively analyzed. Simulation by the finite element method (FEM) is done to calculate the temperature distribution and the thermal-induced phase shift errors in the fiber coils. Simulation results reveal that D-CYL fiber coil itself has fragile performance when it experiences an axially asymmetrical temperature gradient. However, the axial fragility performance could be improved when the D-CYL coil meshes with a heat-off spool. Through further simulations we find that once the D-CYL coil is provided with an axially symmetrical temperature environment, the thermal performance of fiber coils with the D-CYL winding method is better than that with the QAD winding method under the same variable temperature conditions. This valuable discovery is verified by two experiments. The D-CYL winding method is thus promising to overcome the temperature fragility of interferometric fiber optic gyroscopes (IFOGs). View Full-Text
Keywords: fiber coil; double-cylinder (D-CYL); quadrupolar (QAD); finite element method (FEM); interferometric fiber optic gyroscope (IFOG) fiber coil; double-cylinder (D-CYL); quadrupolar (QAD); finite element method (FEM); interferometric fiber optic gyroscope (IFOG)
Figures
