Study and Experiment on Non-Contact Voltage Sensor Suitable for Three-Phase Transmission Line
Previous Article in Journal
Integrating Sensors into a Marine Drone for Bathymetric 3D Surveys in Shallow Waters
Article Menu

Export Article

Open AccessArticle
Sensors 2016, 16(1), 30; doi:10.3390/s16010030

An Analog-Digital Mixed Measurement Method of Inductive Proximity Sensor

†,* ,
and
The School of Electronic and Information Engineering, Xi’an Jiaotong University, No.28, Xianning West Road, Xi’an 710049, China
These authors contributed equally to this work.
*
Author to whom correspondence should be addressed.
Academic Editor: Vittorio M. N. Passaro
Received: 29 October 2015 / Revised: 16 December 2015 / Accepted: 21 December 2015 / Published: 30 December 2015
(This article belongs to the Section Physical Sensors)

Abstract

Inductive proximity sensors (IPSs) are widely used in position detection given their unique advantages. To address the problem of temperature drift, this paper presents an analog-digital mixed measurement method based on the two-dimensional look-up table. The inductance and resistance components can be separated by processing the measurement data, thus reducing temperature drift and generating quantitative outputs. This study establishes and implements a two-dimensional look-up table that reduces the online computational complexity through structural modeling and by conducting an IPS operating principle analysis. This table is effectively compressed by considering the distribution characteristics of the sample data, thus simplifying the processing circuit. Moreover, power consumption is reduced. A real-time, built-in self-test (BIST) function is also designed and achieved by analyzing abnormal sample data. Experiment results show that the proposed method obtains the advantages of both analog and digital measurements, which are stable, reliable, and taken in real time, without the use of floating-point arithmetic and process-control-based components. The quantitative output of displacement measurement accelerates and stabilizes the system control and detection process. The method is particularly suitable for meeting the high-performance requirements of the aviation and aerospace fields. View Full-Text
Keywords: inductive proximity sensor; analog-digital mixed measurement method; two-dimensional look-up table; built-in self-test; position detection inductive proximity sensor; analog-digital mixed measurement method; two-dimensional look-up table; built-in self-test; position detection
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
