Finite Element Analysis of Electrically Excited Quartz Tuning Fork Devices

,
,
,
,
 and *
Received: 1 March 2013; in revised form: 22 May 2013 / Accepted: 28 May 2013 / Published: 30 May 2013
(This article belongs to the Special Issue Piezoelectric Sensors and Actuators)
View Full-Text   |   Download PDF [1043 KB, updated 21 June 2014; original version uploaded 21 June 2014]   |   Browse Figures
Abstract: Quartz Tuning Fork (QTF)-based Scanning Probe Microscopy (SPM) is an important field of research. A suitable model for the QTF is important to obtain quantitative measurements with these devices. Analytical models have the limitation of being based on the double cantilever configuration. In this paper, we present an electromechanical finite element model of the QTF electrically excited with two free prongs. The model goes beyond the state-of-the-art of numerical simulations currently found in the literature for this QTF configuration. We present the first numerical analysis of both the electrical and mechanical behavior of QTF devices. Experimental measurements obtained with 10 units of the same model of QTF validate the finite element model with a good agreement.
