A Four-Quadrant PVDF Transducer for Surface Acoustic Wave Detection

, * ,
,
,
,
,
 and
Received: 1 July 2012; in revised form: 17 July 2012 / Accepted: 25 July 2012 / Published: 2 August 2012
(This article belongs to the Section Physical Sensors)
View Full-Text   |   Download PDF [1147 KB, uploaded 21 June 2014]   |   Browse Figures
Abstract: In this paper, a polyvinylidene fluoride (PVDF) piezoelectric transducer was developed to detect laser-induced surface acoustic waves in a SiO2-thin film–Si-substrate structure. In order to solve the problems related to, firstly, the position of the probe, and secondly, the fact that signals at different points cannot be detected simultaneously during the detection process, a four-quadrant surface acoustic wave PVDF transducer was designed and constructed for the purpose of detecting surface acoustic waves excited by a pulse laser line source. The experimental results of the four-quadrant piezoelectric detection in comparison with the commercial nanoindentation technology were consistent, the relative error is 0.56%, and the system eliminates the piezoelectric surface wave detection direction deviation errors, improves the accuracy of the testing system by 1.30%, achieving the acquisition at the same time at different testing positions of the sample.
Keywords: laser-induced surface acoustic wave; piezoelectric transducer; PVDF transducer; four-quadrant arrangement laser-induced surface acoustic wave; piezoelectric transducer; PVDF transducer; four-quadrant arrangement
