Sensing Pressure Distribution on a Lower-Limb Exoskeleton Physical Human-Machine Interface
ARTS Lab, Scuola Superiore Sant'Anna, viale Rinaldo Piaggio 34, 56025, Pontedera (Pi), Italy
Biorobotics Laboratory, Institute of Bioengineering, Ecole Polytechnique Fédérale de Lausanne (EPFL), CH-1015, Lausanne, Switzerland
Biomechanical Engineering Laboratory, Institute for Biomedical Technology and Technical Medicine (MIRA), University of Twente, 7500 EA Enschede, The Netherlands
* Author to whom correspondence should be addressed.
Received: 1 November 2010; in revised form: 22 November 2010 / Accepted: 24 December 2010 / Published: 28 December 2010
Abstract: A sensory apparatus to monitor pressure distribution on the physical human-robot interface of lower-limb exoskeletons is presented. We propose a distributed measure of the interaction pressure over the whole contact area between the user and the machine as an alternative measurement method of human-robot interaction. To obtain this measure, an array of newly-developed soft silicone pressure sensors is inserted between the limb and the mechanical interface that connects the robot to the user, in direct contact with the wearer’s skin. Compared to state-of-the-art measures, the advantage of this approach is that it allows for a distributed measure of the interaction pressure, which could be useful for the assessment of safety and comfort of human-robot interaction. This paper presents the new sensor and its characterization, and the development of an interaction measurement apparatus, which is applied to a lower-limb rehabilitation robot. The system is calibrated, and an example its use during a prototypical gait training task is presented.
Keywords: human-robot interaction; physical human-machine interface; distributed force sensor; lower-limb exoskeleton
