Optoelectronic Nanodevices

Edited by
April 2020
338 pages
  • ISBN978-3-03928-696-6 (Paperback)
  • ISBN978-3-03928-697-3 (PDF)

This book is a reprint of the Special Issue Optoelectronic Nanodevices that was published in

Chemistry & Materials Science
Engineering
Summary
During the last decade, novel graphene related materials (GRMs), perovskites, as well as metal oxides and other metal nanostructures have received the interest of the scientific community. Due to their extraordinary physical, optical, thermal, and electrical properties, which are correlated with their 2D ultrathin atomic layer structure, large interlayer distance, ease of functionalization, and bandgap tunability, these nanomaterials have been applied in the development or the improvement of innovative optoelectronic applications, as well as the expansion of theoretical studies and simulations in the fast-growing fields of energy (photovoltaics, energy storage, fuel cells, hydrogen storage, catalysis, etc.), electronics, photonics, spintronics, and sensing devices. The continuous nanostructure-based applications development has provided the ability to significantly improve existing products and to explore the design of materials and devices with novel functionalities. This book demonstrates some of the most recent trends and advances in the interdisciplinary field of optoelectronics. Most articles focus on light emitting diodes (LEDs) and solar cells (SCs), including organic, inorganic, and hybrid configurations, whereas the rest address photodetectors, transistors, and other well-known dynamic optoelectronic devices. In this context, this exceptional collection of articles is directed at a broad scientific audience of chemists, materials scientists, physicists, and engineers, with the goals of highlighting the potential of innovative optoelectronic applications incorporating nanostructures and inspiring their realization.
Format
  • Paperback
License
© 2020 by the authors; CC BY-NC-ND license
Keywords
localized surface plasmon; green LED; cathodoluminescence; FDTD; NiCo2S4 nanotubes; Ti porous film; quantum dot; solar cells; counter electrode; metasurfaces; orthogonal polarization; high-efficiency; polarization analyzer; green LEDs; InGaN/GaN superlattice; V-pits; external quantum efficiency; PeLEDs; OAB; perovskite; quantum confinement effect; transparent electrode; Ag film; nucleation layer; organic solar cell; graphene oxide; oxidation; photodetector; light-emitting diodes; quantum dots; stability; color-conversion efficiency; photoluminescence; p-type InGaN; graded indium composition; hole injection; quantum efficiency; green LED; 2D perovskite; controllable synthesis; flexible substrate; photodetector; photoelectric performance; photodetector; organic; photomultiplication; tunneling; external quantum efficiency; liquid crystals; metasurfaces; plasmonics; actively tunable nanodevices; solvent; compact; smooth; perovskite solar cells; indium nanoparticles (In NPs); textured silicon solar cells; antireflective coating (ARC); plasmonic forward scattering; InN/p-GaN heterojunction; interface; photovoltaics; GaN; LED; nano-grating; metamaterials; mid infrared; graphene split-ring; gold split-ring; electromagnetically induced transparency effect; transparent conductive electrode; Ga2O3; AlGaN-based ultraviolet light-emitting diode; transmittance; sheet resistance; electrowetting; tunable absorbers; subwavelength metal grating; plasmon resonance; field emission; graphene; reduced graphene oxide; polymer composites; graphene ink; cold cathode; Fowler–Nordheim; CdTe microdots; Schottky barrier; photodetector; piezo-phototronic effect; UV LEDs; double-layer ITO; pinhole pattern; current spreading; light output power; flip-chip mini-LED; prism-structured sidewall; waveguide photons; light extraction; erbium; silicon transistor; photocurrent; colorimetry; excitation wavelength; light-emitting diode; quantum dots; ternary organic solar cells; graphene ink; functionalization; air-processed; cascade effect; charge transfer; n/a
