Prosthesis, Volume 4, Issue 1 (March 2022) – 14 articles

The main objective of this narrative review was to provide an overview of DEFS (Diagnostic Esthetic Functional Splint), namely CAD/CAM manufactured, “snap-retained”, tooth-colored splints available by materials exhibiting a certain degree of elasticity (like polycarbonates or acetal resins) for restoring function, esthetics and occlusion in several clinical situations, before or as an intermediate alternative to undergoing the final treatment. The search strategy included all papers dealing with snap-retained prosthetic systems and was based on a literature review of papers available in electronic databases (Pubmed/Medline, Evidence-Based Dentistry, BMJ Evidence-Based Medicine, Dynamed, Embase, BMJ Clinical Evidence, Web of Science, Scientific reports); eligible papers were researched on Opengreyand a manual search was performed, as well. From the electronic databases emerged 13,199 records, many of which were duplicates. The grey literature and the manual research did not produce any eligible article. After duplicates removal, 7690 records were obtained. Titles, abstracts and keywords were analyzed. The studies concerning the topic of interest were examined by the reviewers and discussed. Although no evidence-based data were found in the literature, according to the authors’ clinical experience, the DEFS (Diagnostic Esthetic Functional Splint) is a very promising solution in multiple clinical situations, due to its diagnostic, therapeutical, functional and esthetic versatility. Full article

Gait quality can influence walking ability and mobility outcomes making it an important part of prosthetic rehabilitation. Prosthetic knee joint designs can influence gait quality, and limited data exists to guide component selection in under-resourced settings. This study compared spatiotemporal and kinematic gait parameters for two common types of friction-based swing-phase controlled prosthetic knee joints. Two-dimensional optical gait analysis was conducted as part of a cross-over study design involving 17 individuals with unilateral transfemoral amputations. Two prosthetic knee joints were compared. One utilized constant-friction (CF) and the other a variable cadence controller (VCC) for swing-phase control. Gait was analyzed at normal and fast walking speeds. Primary gait parameters included swing-phase time, step length, and knee flexion. Swing-phase time and peak knee flexion angles, as well as their related symmetry indices, were lower for the VCC compared to the CF (p < 0.01), by 11.1 to 94.1%. The VCC resulted in faster walking speeds by approximately 15% compared to the CF (p = 0.002). Friction-based swing-phase knee control mechanisms can facilitate an appropriate and cost-effective prosthetic knee joint solution in under-resourced settings. The findings suggest that friction-based mechanism can be designed to improve gait quality, and in turn overall walking performance. Full article

This article introduces a novel approach to digitize legislation using rule based-decision trees (RBDTs). As regulation is one of the major barriers to innovation, novel methods for helping stakeholders better understand, and conform to, legislation are becoming increasingly important. Newly introduced medical device regulation has resulted in an increased complexity of regulatory strategy for manufacturers, and the pressure on notified body resources to support this process is making this an increasing concern in industry. This paper explores a real-world classification problem that arises for medical device manufacturers when they want to be certified according to the In Vitro Diagnostic Regulation (IVDR). A modification to an existing RBDT algorithm is introduced (RBDT-1C) and a case study demonstrates how this method can be applied. The RBDT-1C algorithm is used to design a decision tree to classify IVD devices according to their risk-based classes: Class A, Class B, Class C and Class D. The applied RBDT-1C algorithm demonstrated accurate classification in-line with published ground-truth data. This approach should enable users to better understand the legislation, has informed policy makers about potential areas for future guidance, and allowed for the identification of errors in the regulations that have already been recognized and amended by the European Commission. Full article

Transcatheter aortic valve replacement (TAVR) has become a milestone for the management of aortic stenosis in a growing number of patients who are unfavorable candidates for surgery. With the new generation of transcatheter heart valves (THV), the feasibility of transcatheter mitral valve replacement (TMVR) for degenerated mitral bioprostheses and failed annuloplasty rings has been demonstrated. In this setting, computational simulations are modernizing the preoperative planning of transcatheter heart valve interventions by predicting the outcome of the bioprosthesis interaction with the human host in a patient-specific fashion. However, computational modeling needs to carry out increasingly challenging levels including the verification and validation to obtain accurate and realistic predictions. This review aims to provide an overall assessment of the recent advances in computational modeling for TAVR and TMVR as well as gaps in the knowledge limiting model credibility and reliability. Full article

One of the key arguments in favor of digitally produced complete dentures (CDs) is the requirement for less patient visits in comparison to the conventional workflow. However, it is not yet clear if this argument is accurate; nor, if indeed the insertion of the complete dentures is achieved in fewer appointments, how many are required. The purpose of this literature review was to investigate the reported number of required patient visits for the production of digitally fabricated CDs. An electronic search was performed in PubMed/MEDLINE using three groups of keywords: “complete dentures”, “CAD/CAM”, and “Appointments” with their alternative forms. Out of the initial 157 results, 36 articles were automatically selected utilizing exclusion keywords. After consensus between the two examiners, eight articles were finally analyzed and presented in a table. The majority (75%) of the reports came from institutions, and the average number of appointments up to complete denture insertion was 4.1, not always including try-in dentures. In this study, it can be concluded that, with a digital workflow, the insertion appointment is reached in fewer visits than the conventional five-visit procedure which is commonly taught in dental schools. Full article

This in vitro study evaluated the surface hydrophobicity of 3D-printed denture base resin exposed to either an extended post-curing light exposure time or a sandblasting procedure. MATERIALS AND METHODS: Disk-shaped samples (diameter × height: 10 mm × 3 mm) were 3D-printed with stereolithography SLA technology using the denture-base resin. Samples were divided into three groups: control, extended UV-post-curing, and sandblasted. The surface roughness parameters for each group were calculated, and the surface hydrophobicity was evaluated by measuring the drop contact angle. Analysis was done using the T-test; significance was when p < 0.05. RESULTS: The comparison of surface roughness parameters showed significant differences between the control group and the sandblasted group (Sa: p = 0.001, Sz: p < 0.001, Str: p < 0.001, Spc: p = 0.044) as well as between the extended-cure group and the sandblasted group (Sa: p = 0.006, Sz: p < 0.001, Str: p < 0.001, Spc: p = 0.036) except for the Sdr measures. The surface hydrophobicity was also statistically lower in the sandblasted group compared to both the control and extended curing groups (p < 0.001). CONCLUSION: The sandblasting procedure created a less hydrophobic surface of the 3D-printed denture base resin, and the altered surface roughness could be a contributor to this observation. Full article

Different techniques can be used to design and manufacture a full-arch, implant-supported prosthesis, and different materials can be chosen for its production, each with its advantages and limitations. One of the possibilities provided by digital tools is their ability to maintain low costs to give more patients the chance to choose this commonly expensive treatment. The present work aims to present a protocol for the realization of full-arch, implant-fixed complete dentures (IFCDs) in monolithic zirconia and titanium. When the analogic master model is obtained, it is scanned to perform the digital wax-up, and the two parts of the prosthesis—a bar in titanium and an aesthetic component in monolithic zirconia—are milled. The dental team must then verify the precision of the milled components on the master model, so that they can be cemented together and delivered to the patient. This technique offers different advantages, in terms of cost sustainability, minimal wear risk for the prosthesis and its antagonists, and ease of re-intervening in the case of complications. The main limitations of the technique may lie in the aesthetic needs of the patient, because of the relatively poor aesthetic performance of monolithic zirconia and the absence of a pink orthopedic component. Full article

For prosthesis users, knee units can range from simple devices costing $2000 up to $45,000 for high-end, microprocessor-controlled systems. These higher-end electronic knees provide significant advantages in stability, gait, and metabolic rate compared to their passive or mechanical counterparts. However, the high cost of such systems makes them inaccessible to most amputees. In this study, it was hypothesized that a microprocessor knee could be manufactured for less than $1000, with comparable stability and user experience to a high-end industry standard device. A prototype (E-Knee) was designed with a specific emphasis on stance stability, and was tested during patient gait trials. The gait trials used a repeated measures design to compare three knee devices (a simple passive knee, the prototype E-Knee, and a high-end knee). Ground reaction forces and a functionality questionnaire were used to compare devices. A microprocessor locking test was used to evaluate the prototype’s ability to prevent falls. Building on the LIMBS M3, a passive four-bar polycentric device, the E-Knee added sensing, computing, and controlling capabilities for a material cost of $507. Initial data from a two-subject trial served as proof-of-concept to validate the prototype and found that it improved gait by providing more stability than the M3 and had more gait-pattern similarities to the Ottobock C-Leg than to the M3. Patients reported no perceived differences in stability between the E-Knee and the C-Leg. Patient trials supported that the E-Knee prototype behaved more naturally than the low-end M3 device and had similar ground reaction forces to the C-Leg. Full article

(1) Background: This study investigated the feasibility of conducting a two-week “real-world” trial of the Self Grasping Hand (SGH), a novel 3D printed passive adjustable prosthesis for hand absence; (2) Methods: Single-group pilot study of nine adults with trans-radial limb absence; five used body-powered split-hooks, and four had passive cosmetic hands as their usual prosthesis. Data from activity monitors were used to measure wear time and bilateral activity. At the end of the two-week trial, function and satisfaction were measured using the Orthotics and Prosthetics Users’ Survey Function Scale (OPUS) and the prosthesis satisfaction sub-scales of the Trinity Amputations and Prosthesis Experience Scale (TAPES). Semi-structured interviews captured consumer feedback and suggestions for improvement; (3) Results: Average SGH wear time over 2 weeks was 17.5 h (10% of total prosthesis wear time) for split-hook users and 83.5 h (63% of total prosthesis wear time) for cosmetic hand users. Mean satisfaction was 5.2/10, and mean function score was 47.9/100; (4) Two-week real-world consumer testing of the SGH is feasible using the methods described. Future SGH designs need to be more robust with easier grasp lock/unlock. Full article

Orthopedic prosthesis infection must be medically managed after appropriate microbiological documentation. While bacteria and fungi are acknowledged to be causative opportunistic pathogens in this situation, the potential role of methanogens in orthopedic prosthesis infections is still unknown. In a retrospective study, a total of 100 joint and bone samples collected from 25 patients were screened by specific PCR assays for the detection of methanogens. PCR-positive samples were observed by autofluorescence, electron microscopy and tentatively cultured under specific culture conditions. Methanogens were detected by quantitative PCR in 4/100 samples, in the presence of negative controls. Sequencing identified Methanobrevibacter oralis in two cases, Methanobrevibacter smithii in one case and Methanobrevibacter wolinii in one case. Microscopic methods confirmed molecular findings and bacterial culture yielded two strains of Staphylococcus aureus, one strain of Staphylococcus epidermidis and one strain of Proteus mirabilis. These unprecedented data highlight the presence of methanogens in joint and bone samples of patients also diagnosed with bacterial orthopedic prosthesis infection, questioning the role of methanogens as additional opportunistic co-pathogens in this situation. Full article

Numerous types of prosthodontics surgical guides, with and without metallic sleeves, have been found to be useful in clinical studies. The aim of this in vitro research was to compare the time required to complete the surgical procedure with two differently designed surgical prosthetic templates. Ten identical prototype models of mandible based on a CBCT and optical scan of a partially edentulous patient with missing teeth numbers 37, 46, and 47 were prepared and then printed. Five of these models were used for implant site preparation with a surgical guide without metal sleeves and dedicated surgical kit, and the other five models were used for the same procedure performed with a surgical guide with metal sleeves and a dedicated surgical kit. The time of implant site preparation was measured and recorded. Statistical analysis was performed using Student’s t-test for independent samples. Differences between groups were found to be statistically significant (t = −9.94; df = 28; p = 0.0000) with a lower value in favor of the surgical templates without metallic sleeves. Different types of prosthodontics surgical guides, with or without metallic sleeves, seemed to be an important factor which can significantly impact the time of implant site preparation and, therefore, the overall surgical procedure. Full article

Objectives: The aim of this retrospective study is to assess whether axial and tilted implants supporting All-on-4 prosthesis show any differences in terms of survival rate, success rate and marginal bone loss (MBL) after a long-term follow-up (mean 9 years). Material and Methods: One hundred and fifty-six implants were included in this study, 78 of which were tilted (Group A) and 78 were axial (Group B). MBL was measured after a mean time of 9 years on periapical radiographs. Success and survival rate were assessed with the Misch criteria. The prevalence of peri-implantitis was calculated. Statistical analysis was conducted to assess comparisons between groups. A Kaplan–Meyer analysis was carried out for the survival rate. Results: A total of 156 implants were analyzed. After a 9-year mean time follow-up, the survival rate was 96.2% in group A and 98.7% in group B; and the success rate was 80.8% in group A and 74.4% in group B. The mean MBL was 1.2 mm (IQR 0.6–1.8) in group A and 1.4 mm (IQR 0.9–2.1) in group B. No statistically significant differences were shown between the two groups (p < 0.05). Peri-implantitis occurred in 15 implants and was equally distributed between the two groups. Conclusions: This study shows that axial and tilted implants have similar success rates, survival rates and MBL values after a long-time follow-up, assessing the biological reliability of the prosthesis they supported. Peri-implantitis occurred equally between the two groups. Full article

The tissue source of type I collagen is critical to ensure scalability and regulation-friendly clinical translation of new medical device prototypes. However, the selection of a commercial source of collagen that fulfils both aforementioned requirements and is compliant with new manufacturing routes is challenging. This study investigates the effect that type I collagen extracted from three different mammalian tissues has on the molecular and macroscopic characteristics of a new UV-cured collagen hydrogel. Pepsin-solubilised bovine atelocollagen (BA) and pepsin-solubilised porcine atelocollagen (PA) were selected as commercially available raw materials associated with varying safety risks and compared with in-house acid-extracted type I collagen from rat tails (CRT). All raw materials displayed the typical dichroic and electrophoretic characteristics of type I collagen, while significantly decreased lysine content was measured on samples of PA. Following covalent functionalisation with 4-vinylbenzyl chloride (4VBC), BA and CRT products generated comparable UV-cured hydrogels with significantly increased averaged gel content (G ≥ 97 wt.%), while the porcine variants revealed the highest swelling ratio (SR = 2224 ± 242 wt.%) and an order of magnitude reduction in compression modulus (E_c = 6 ± 2 kPa). Collectively, these results support the use of bovine tissues as a chemically viable source of type I collagen for the realisation of UV-cured hydrogels with competitive mechanical properties and covalent network architectures. Full article
