Open AccessArticle
Nanomaterials 2017, 7(9), 233; doi:10.3390/nano7090233

Highly Efficient and Stable Organic Solar Cells via Interface Engineering with a Nanostructured ITR-GO/PFN Bilayer Cathode Interlayer

State Key Laboratory of Electronic Thin Films and Integrated Devices, School of Optoelectronic Information, University of Electronic Science and Technology of China (UESTC), Chengdu 610054, China
*
Author to whom correspondence should be addressed.
Received: 22 July 2017 / Revised: 10 August 2017 / Accepted: 21 August 2017 / Published: 23 August 2017
(This article belongs to the Special Issue Nanomaterials for Renewable and Sustainable Energy)
View Full-Text   |   Download PDF [5561 KB, uploaded 23 August 2017]   |

Abstract

An innovative bilayer cathode interlayer (CIL) with a nanostructure consisting of in situ thermal reduced graphene oxide (ITR-GO) and poly[(9,9-bis(3′-(N,N-dimethylamion)propyl)-2,7-fluorene)-alt-2,7-(9,9-dioctyl) fluorene] (PFN) has been fabricated for inverted organic solar cells (OSCs). An approach to prepare a CIL of high electronic quality by using ITR-GO as a template to modulate the morphology of the interface between the active layer and electrode and to further reduce the work function of the electrode has also been realized. This bilayer ITR-GO/PFN CIL is processed by a spray-coating method with facile in situ thermal reduction. Meanwhile, the CIL shows a good charge transport efficiency and less charge recombination, which leads to a significant enhancement of the power conversion efficiency from 6.47% to 8.34% for Poly({4,8-bis[(2-ethylhexyl)oxy]benzo[1,2-b:4,5-b′]dithiophene-2,6-diyl}{3-fluoro-2-[(2-ethylhexyl)carbonyl]thieno[3,4-b]thiophenediyl} (PTB7):[6,6]-phenyl-C71-butyric acid methyl ester (PC71BM)-based OSCs. In addition, the long-term stability of the OSC is improved by using the ITR-GO/PFN CIL when compared with the pristine device. These results indicate that the bilayer ITR-GO/PFN CIL is a promising way to realize high-efficiency and stable OSCs by using water-soluble conjugated polymer electrolytes such as PFN. View Full-Text
Keywords: organic solar cell; reduced graphene oxide; PFN; bilayer cathode interlayer; in situ thermal reduction organic solar cell; reduced graphene oxide; PFN; bilayer cathode interlayer; in situ thermal reduction
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Zheng, D.; Zhao, L.; Fan, P.; Ji, R.; Yu, J. Highly Efficient and Stable Organic Solar Cells via Interface Engineering with a Nanostructured ITR-GO/PFN Bilayer Cathode Interlayer. Nanomaterials 2017, 7, 233.
