Lubricants 2018, 6(1), 21; https://doi.org/10.3390/lubricants6010021

Design Optimization of an Automotive Turbocharger Thrust Bearing Using a CFD-Based THD Computational Approach

1
School of Naval Architecture and Marine Engineering, National Technical University of Athens, Zografos, 157 80 Athina, Greece
2
Mitsubishi Turbocharger and Engine Europe B.V., 1332 EC Almere, The Netherlands
This paper is an extended version of a paper published in 16th EDF-PPRIME workshop on Behavior of journal and thrust bearings under transient and mixed lubrication regime Futuroscope, France, 5–6 October 2017.
*
Author to whom correspondence should be addressed.
Received: 24 December 2017 / Revised: 12 February 2018 / Accepted: 13 February 2018 / Published: 22 February 2018
(This article belongs to the Special Issue Friction and Lubrication of Sliding Bearings)
Full-Text   |   PDF [13424 KB, uploaded 24 February 2018]   |

Abstract

In a quest to reduce fuel consumption and emissions of automotive combustion engines, friction losses from many different sources need to be minimized. For modern designs of turbochargers commonly used in the automotive industry, reduction of friction losses results in better efficiency and also contributes to a faster transient response. The thrust bearing is one of the main contributors to the mechanical losses of a turbocharger. Therefore, it is crucial to optimize the design of the thrust bearing so that it has minimum friction losses while keeping sufficient thrust carrying capacity. One of the main challenges of turbocharger thrust bearing design, is that rotation speed is not fixed: the turbocharger may have a rotation speed which varies between 0 to as much as 250 kRPM. Moreover, the thrust bearing generates considerable heat, which changes the temperature of the oil film and its surroundings. In the present work, the design of the thrust bearing of an automotive turbocharger has been optimized. A CFD-based Thermohydrodynamic (THD) computational approach has been developed, taking into consideration heat dissipation, conjugate heat transfer throughout the bearing domain including the surrounding parts, as well as shear thinning and cavitation in the lubricant domain. An optimizer has been coupled to the CFD solver, with the aim of identifying bearing designs with reduced friction losses. Two bearing concepts have been evaluated: a taper-land design—which is a commonly applied thrust bearing concept—as well as a pocket bearing design. The resulting optimum pocket designs exhibit improved performance, in comparison to the optimum taper-land design. The present results indicate that (a) the pocket design concept can substantially contribute to further reducing the friction losses of a turbocharger, and (b) optimal design parameters of pocket bearings depend on the specific application (size, operating conditions), therefore detailed calculations should be performed to verify optimum performance. View Full-Text
Keywords: THD; thrust bearing; turbocharger; cavitation; shear thinning; optimization; CFD THD; thrust bearing; turbocharger; cavitation; shear thinning; optimization; CFD
Figures

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Charitopoulos, A.G.; Visser, R.; Eling, R.; Papadopoulos, C.I. Design Optimization of an Automotive Turbocharger Thrust Bearing Using a CFD-Based THD Computational Approach. Lubricants 2018, 6, 21.
