Open AccessArticle
Polymers 2017, 9(7), 278; https://doi.org/10.3390/polym9070278

Modeling Diffractive Lenses Recording in Environmentally Friendly Photopolymer

1
I.U. Física Aplicada a las Ciencias y las Tecnologías Universidad de Alicante, P.O. Box 99, E-03080 Alicante, Spain
2
Departmento de Física, Ing. de Sistemas y Teoría de la Señal, Universidad de Alicante, P.O. Box 99, E-03080 Alicante, Spain
*
Author to whom correspondence should be addressed.
Academic Editors: John T. Sheridan and Yanlei Yu
Received: 25 May 2017 / Revised: 29 June 2017 / Accepted: 6 July 2017 / Published: 12 July 2017
(This article belongs to the Special Issue Photo-Responsive Polymers)
View Full-Text   |   Download PDF [2999 KB, uploaded 12 July 2017]   |

Abstract

The improvements made in diffusion models simulating phase image recording in photopolymers enable the optimization of a wide range of complex diffractive optical elements (DOEs), while the miniaturization of spatial light modulators makes it possible to generate both symmetric and non-symmetric DOEs. In addition, there is increasing interest in the design of new friendly recording materials. In this respect, photopolymers are a promising material due to their optical properties. In this paper, we show a procedure to record diffractive spherical lenses using a nontoxic optimized photopolymer. To achieve this goal, we followed three steps: first, the chemical optimization for DOE recording; second, the recording material characterization to be simulated by a three-dimensional diffusion model; and third, the evaluation of the coverplating for the conservation of the DOE. View Full-Text
Keywords: diffractive optics; optical recording materials; photopolymers; diffusion model; spatial light modulation diffractive optics; optical recording materials; photopolymers; diffusion model; spatial light modulation
Figures

Figure 1
