Mechanical, Thermal, and Electrical Properties of Graphene-Epoxy Nanocomposites—A Review
Abstract
:1. Introduction
2. Epoxy as Matrix
3. Graphene as Reinforcement
4. Fracture Toughness
5. Structure and Fracture Toughness
6. Surface Area and Fracture Toughness
7. Weight Fraction and Fracture Toughness
8. Dispersion State and Fracture Toughness
9. Functionalization and Fracture Toughness
10. Crosslink Density and Fracture Toughness
11. Fracture Patterns
12. Other Mechanical Properties
13. Thermal Properties
14. Electrical Properties
15. Conclusions
- Epoxy is an excellent matrix for graphene composites because of its efficient properties such as enhancement in composite mechanical properties, processing flexibility, and acceptable cost [2].
- Graphene can significantly enhance the fracture toughness of epoxy nanocomposites—i.e., up to 131% [59]. When epoxy is reinforced with graphene, the carbonaceous sheets shackle the crack and restrict its advancement. This obstruction and deflection of the crack by the graphene at the interface is the foremost mechanism of raising the fracture toughness of nanocomposites.
- The graphene sheets with smaller length, width, and thickness are more efficient in improving the fracture toughness than those with larger dimensions [57]. Large graphene sheets have a high stress concentration factor, because of which crack generation becomes easy in the epoxy matrix [118,119]. The cracks deteriorate the efficiency of graphene in enhancing the fracture toughness of epoxy/graphene nanocomposites.
- Uniformly dispersed graphene improves fracture toughness significantly as compared to the poorly dispersed graphene [72]. It is evident from the published literature that the fracture toughness dropped when graphene weight fraction was increased beyond 1 wt %. The decrease in fracture toughness with higher weight fraction of graphene can be correlated with the dispersion state of graphene. As graphene weight fraction increases beyond 1 wt %, the dispersion state becomes inferior.
- Three roll milling or calendering process is an efficient way of dispersing the reinforcement into a polymer matrix, as it involves high shear forces [244,245,246,247,248]. However, the maximum enhancement in fracture toughness was achieved with a combination of sonication and mechanical stirring [59].
- In thermosetting materials such as epoxy, high crosslink density is desirable for improved mechanical properties. However, fracture toughness is dropped with high crosslinking [57].
- The literature has proved the absence of consensus of graphene’s role in improving the mechanical properties of nanocomposites [150,151,152,153,154]. Generally, graphene acts as panacea and raises the mechanical properties [116,155,156,157,158]. On the contrary, it acts as placebo and shows no effect on mechanical properties. Even worse, it is inimical and razes the mechanical properties [160,161,162,163,164]. The main factors that dictate graphene’s influence on the mechanical properties of epoxy nanocomposites include topographical features, morphology, weight fraction, dispersion state, surface modifications, and interfacial interactions.
Acknowledgments
Author Contributions
Conflicts of Interest
Abbreviations
3DGN | Three dimensional graphene network |
3RM | Three roll milling |
A | Aramid fibers |
APTS-GO | Amino-functionalized graphene oxide (GO) |
ATGO | 3-Aminopropyltriethoxysilane functionalized silica nanoparticles attached GO |
ATP | Attapulgite |
ATS | 3-amino functionalized silica nanoparticles |
BM | Ball milling |
CM | Centrifugal mixing |
CNF | Carbon nanofiber |
CNFs | Vapor grown carbon nanofibers |
CNTs | Carbon nanotubes |
DDS | Diaminodiphenylsulfone |
DGEBA-f-GO | Diglycidyl ether of bisphenol-A functionalized GO |
DRA | Discontinuously reinforced aluminum |
DRTi | Discontinously reinforced titanium |
EGNPs | Amine functionalized expanded graphene nanoplatelets |
EMCs | Epoxy matrix composites |
fGnPs | Polybenzimidazole functionalized graphene platelets (GnPs) |
GF | Graphene foam |
G-NH2 | Amino-functionalized GNPs |
GnPs | Graphene platelets |
GNPs* | Graphite nanoplatelets |
GNs | Amine functionalized graphene sheets |
GNSs | Graphene nanosheets |
GO | Graphene oxide |
GP | Graphite particles |
GPLs | Graphene nanoplatelets |
GPTS-GO | Epoxy functionalized GO |
G-Si | Silane modified GNPs |
HPH + 3RM | High pressure homogenizer + three roll milling |
HSM | High speed mixing |
m-clay | Surface modified nano clay |
m-CNFs | Triazole functionalized carbon nanofibers |
MERGO | Microwave exfoliated reduced graphene oxide |
m-GnP | Surface modified GnP |
m-GnP* | Surfactant modified graphene platelets |
m-GP | Surface modified graphene platelets |
MgSr | Magnetic stirring |
MLG | Multi-layer graphene |
MS | Mechanical stirring |
MS + USn | Mechanical stirring + Ultrasonication |
MWCNTs | Multi-walled carbon nanotubes |
MWNTs | Multi-walled carbon nanotubes |
ND | Nanodiamond |
P | Polyacrylonitrile (PAN) fibers |
p-CNFs | Pristine carbon nanofibers |
PEA | Polyetheramine |
phr | Per hundred parts of resin |
PMCs | Polymer matrix composites |
Q/I | Quasi-isotropic |
RGO | Thermally reduced graphene oxide |
SA | Surface area |
SATPGO | 3-Aminopropyltriethoxysilane modified silica nanoparticles attached graphene oxide |
SCFs | Short carbon fibers |
ShM | Shear mixing |
Silane-f-GO | Silane functionalized GO |
SM | Speed mixing |
Sn | Sonication |
Sn + BM | Sonication + Ball milling |
Sn + MgSr | Sonication + Magnetic stirring |
Sn + MS | Sonication + Mechanical stirring |
SnP | Silver nanoparticles |
SnW | Silver nanowires |
SWCNTs | Single-walled carbon nanotubes |
SWNTs | Single-walled carbon nanotubes |
TEM | Transmission electron microscopy |
TPE | Two phase extraction |
UG | Unmodified graphene nanoplatelets |
U-GnP | Unmodified graphene platelets |
USn | Ultrasonication |
