Polymers 2018, 10(1), 55; https://doi.org/10.3390/polym10010055

Transparent Low Electrostatic Charge Films Based on Carbon Nanotubes and Polypropylene. Homopolymer Cast Films

1
Innovación y Desarrollo en Materiales Avanzados A.C., Grupo POLYnnova, Carr. San Luis Potosí-Guadalajara 1510, Nivel 3, Local 12, Lomas del Tecnológico, San Luis Potosí S.L.P. C.P. 78211, Mexico
2
CONACyT—Centro de Investigación en Química Aplicada, Blvd. Enrique Reyna H. 140, Col. San José de los Cerritos, Saltillo, Coahuila C.P. 25294, Mexico
3
Centro de Investigación en Química Aplicada, Blvd. Ing. Enrique Reyna H. 140, Col. San José de los Cerritos, Saltillo, Coahuila C.P. 25294, Mexico
*
Authors to whom correspondence should be addressed.
Received: 25 November 2017 / Revised: 20 December 2017 / Accepted: 3 January 2018 / Published: 9 January 2018
(This article belongs to the Special Issue Polymer Nanocomposites)
View Full-Text   |   Download PDF [5165 KB, uploaded 9 January 2018]   |

Abstract

Use of multi-wall carbon nanotubes (MWCNTs) in external layers (A-layers) of ABA-trilayer polypropylene films was investigated, with the purpose of determining intrinsic and extrinsic factors that could lead to antistatic behavior of transparent films. The incorporation of 0.01, 0.1, and 1 wt % of MWCTNs in the A-layers was done by dilution through the masterbatch method. Masterbatches were fabricated using isotactic polypropylene (iPP) with different melt flow indexes 2.5, 34, and 1200 g/10 min, and using different ultrasound assist methods. It was found that films containing MWCNTs show surface electrical resistivity of 1012 and 1016 Ω/sq, regardless of the iPP melt flow index (MFI) and masterbatch fabrication method. However, electrostatic charge was found to depend upon the iPP MFI, the ultrasound assist method and MWCNT concentration. A percolation electron transport mechanism was determined most likely responsible for this behavior. Optical properties for films containing MWCNTs do not show significant differences compared to the reference film at MWCNT concentrations below 0.1 wt %. However, an enhancement in brightness was observed, and it was attributed to ordered iPP molecules wrapping the MWCNTs. Bright transparent films with low electrostatic charge were obtained even for MWCNTs concentrations as low as 0.01 wt %. View Full-Text
Keywords: polymer films; extrusion; cast; carbon nanotube; antistatic; optical properties polymer films; extrusion; cast; carbon nanotube; antistatic; optical properties
Figures

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Supplementary material

SciFeed

Share & Cite This Article

MDPI and ACS Style

Quiñones-Jurado, Z.V.; Waldo-Mendoza, M.Á.; Mata-Padilla, J.M.; González-Morones, P.; Martínez-Colunga, J.G.; Soriano-Corral, F.; Cruz-Delgado, V.J.; Ziolo, R.F.; Avila-Orta, C.A. Transparent Low Electrostatic Charge Films Based on Carbon Nanotubes and Polypropylene. Homopolymer Cast Films. Polymers 2018, 10, 55.
