Open AccessArticle
Remote Sens. 2017, 9(5), 448; doi:10.3390/rs9050448

Quantifying Changes of Villages in the Urbanizing Beijing Metropolitan Region: Integrating Remote Sensing and GIS Analysis

1
State Key Laboratory of Urban and Regional Ecology, Research Center for Eco-Environmental Sciences, Chinese Academy of Sciences, Beijing 100085, China
2
University of Chinese Academy of Sciences, Beijing 100049, China
3
Chinese Academy for Environmental Planning, Beijing 100012, China
4
Beijing Institute of Surveying and Mapping, Beijing 100038, China
*
Author to whom correspondence should be addressed.
Academic Editors: Conghe Song, Junxiang Li, Weiqi Zhou, James Campbell and Prasad S. Thenkabail
Received: 15 March 2017 / Revised: 16 April 2017 / Accepted: 3 May 2017 / Published: 6 May 2017
(This article belongs to the Special Issue Remote Sensing of Urban Ecology)
View Full-Text   |   Download PDF [4335 KB, uploaded 6 May 2017]   |

Abstract

Rapid urbanization has resulted in great changes in rural landscapes globally. Using remote sensing data to quantify the distribution of rural settlements and their changes has received increasing attention in the past three decades, but remains a challenge. Previous studies mostly focused on the residential changes within a grid or administrative boundary, but not at the individual village level. This paper presents a new change detection approach for rural residential settlements, which can identify different types of rural settlement changes at the individual village level by integrating remote sensing and Geographic Information System (GIS) analyses. Using multi-temporal Landsat TM image data, this approach classifies villages into five types: “no change”, “totally lost”, “shrinking”, “expanding”, and “merged”, in contrast to the commonly used “increase” and “decrease”. This approach was tested in the Beijing metropolitan area from 1984 to 2010. Additionally, the drivers of such changes were investigated using multinomial logistic regression models. The results revealed that: (1) 36% of the villages were lost, but the total area of developed lands in existing villages increased by 34%; (2) Changes were dominated by the type of ‘expansion’ in 1984–1990 (accounted for 43.42%) and 1990–2000 (56.21%). However, from 2000 to 2010, 49.73% of the villages remained unchanged; (3) Both topographical factors and distance factors had significant effects on whether the villages changed or not, but their impacts changed through time. The topographical driving factors showed decreasing effects on the loss of rural settlements, while distance factors had increasing impacts on settlement expansion and merging. This approach provides a useful tool for better understanding the changes in rural residential settlements and their associations with urbanization. View Full-Text
Keywords: villages; rural settlement; spatial patterns; changes; driving factors; remote sensing; GIS; Beijing metropolitan region villages; rural settlement; spatial patterns; changes; driving factors; remote sensing; GIS; Beijing metropolitan region
Figures

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Wang, K.; Zhou, W.; Xu, K.; Liang, H.; Yu, W.; Li, W. Quantifying Changes of Villages in the Urbanizing Beijing Metropolitan Region: Integrating Remote Sensing and GIS Analysis. Remote Sens. 2017, 9, 448.
