Remote Sens. 2017, 9(4), 372; doi:10.3390/rs9040372

Evaluation of Remote Sensing Inversion Error for the Above-Ground Biomass of Alpine Meadow Grassland Based on Multi-Source Satellite Data

1
State Key Laboratory of Grassland Agro-ecosystems, College of Pastoral Agriculture Science and Technology, Lanzhou University, Lanzhou 730020, China
2
Key Laboratory of Western China’s Environmental Systems (Ministry of Education), College of Earth and Environmental Sciences, Lanzhou University, Lanzhou 730000, China
3
Laboratory for Remote Sensing and Geoinformatics, University of Texas at San Antonio, San Antonio, TX 78249, USA
*
Author to whom correspondence should be addressed.
Academic Editors: Lalit Kumar, Onisimo Mutanga, Lars T. Waser and Prasad S. Thenkabail
Received: 21 January 2017 / Revised: 4 April 2017 / Accepted: 13 April 2017 / Published: 16 April 2017
(This article belongs to the Special Issue Remote Sensing of Above Ground Biomass)
View Full-Text   |   Download PDF [3648 KB, uploaded 16 April 2017]   |

Abstract

It is not yet clear whether there is any difference in using remote sensing data of different spatial resolutions and filtering methods to improve the above-ground biomass (AGB) estimation accuracy of alpine meadow grassland. In this study, field measurements of AGB and spectral data at Sangke Town, Gansu Province, China, in three years (2013–2015) are combined to construct AGB estimation models of alpine meadow grassland based on these different remotely-sensed NDVI data: MODIS, HJ-1B CCD of China and Landsat 8 OLI (denoted as NDVIMOD, NDVICCD and NDVIOLI, respectively). This study aims to investigate the estimation errors of AGB from the three satellite sensors, to examine the influence of different filtering methods on MODIS NDVI for the estimation accuracy of AGB and to evaluate the feasibility of large-scale models applied to a small area. The results showed that: (1) filtering the MODIS NDVI using the Savitzky–Golay (SG), logistic and Gaussian approaches can reduce the AGB estimation error; in particular, the SG method performs the best, with the smallest errors at both the sample plot scale (250 m × 250 m) and the entire study area (33.9% and 34.9%, respectively); (2) the optimum estimation model of grassland AGB in the study area is the exponential model based on NDVIOLI, with estimation errors of 29.1% and 30.7% at the sample plot and the study area scales, respectively; and (3) the estimation errors of grassland AGB models previously constructed at different spatial scales (the Tibetan Plateau, Gannan Prefecture and Xiahe County) are higher than those directly constructed based on the small area of this study by 11.9%–36.4% and 5.3%–29.6% at the sample plot and study area scales, respectively. This study presents an improved monitoring algorithm of alpine natural grassland AGB estimation and provides a clear direction for future improvement of the grassland AGB estimation and grassland productivity from remote sensing technology. View Full-Text
Keywords: alpine meadow grassland; above-ground biomass; inversion model; error analysis; applicability evaluation alpine meadow grassland; above-ground biomass; inversion model; error analysis; applicability evaluation
Figures

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Meng, B.; Ge, J.; Liang, T.; Yang, S.; Gao, J.; Feng, Q.; Cui, X.; Huang, X.; Xie, H. Evaluation of Remote Sensing Inversion Error for the Above-Ground Biomass of Alpine Meadow Grassland Based on Multi-Source Satellite Data. Remote Sens. 2017, 9, 372.
