Remote Sens. 2016, 8(1), 16; doi:10.3390/rs8010016

An Automated Approach for Mapping Persistent Ice and Snow Cover over High Latitude Regions

1
U.S. Geological Survey, Alaska Science Center, 4210 University Drive, Anchorage, AK 99508, USA
2
Department of Geography, University of Utah, 260 S. Central Campus Dr., Room 270, Salt Lake City, UT 84112, USA
*
Author to whom correspondence should be addressed.
Academic Editors: Daniel J. Hayes, Santonu Goswami, Guido Grosse, Benjamin Jones, Richard Gloaguen and Prasad S. Thenkabail
Received: 30 June 2015 / Revised: 4 December 2015 / Accepted: 21 December 2015 / Published: 25 December 2015
(This article belongs to the Special Issue Remote Sensing of Changing Northern High Latitude Ecosystems)
View Full-Text   |   Download PDF [5891 KB, uploaded 25 December 2015]   |

Abstract

We developed an automated approach for mapping persistent ice and snow cover (glaciers and perennial snowfields) from Landsat TM and ETM+ data across a variety of topography, glacier types, and climatic conditions at high latitudes (above ~65°N). Our approach exploits all available Landsat scenes acquired during the late summer (1 August–15 September) over a multi-year period and employs an automated cloud masking algorithm optimized for snow and ice covered mountainous environments. Pixels from individual Landsat scenes were classified as snow/ice covered or snow/ice free based on the Normalized Difference Snow Index (NDSI), and pixels consistently identified as snow/ice covered over a five-year period were classified as persistent ice and snow cover. The same NDSI and ratio of snow/ice-covered days to total days thresholds applied consistently across eight study regions resulted in persistent ice and snow cover maps that agreed closely in most areas with glacier area mapped for the Randolph Glacier Inventory (RGI), with a mean accuracy (agreement with the RGI) of 0.96, a mean precision (user’s accuracy of the snow/ice cover class) of 0.92, a mean recall (producer’s accuracy of the snow/ice cover class) of 0.86, and a mean F-score (a measure that considers both precision and recall) of 0.88. We also compared results from our approach to glacier area mapped from high spatial resolution imagery at four study regions and found similar results. Accuracy was lowest in regions with substantial areas of debris-covered glacier ice, suggesting that manual editing would still be required in these regions to achieve reasonable results. The similarity of our results to those from the RGI as well as glacier area mapped from high spatial resolution imagery suggests it should be possible to apply this approach across large regions to produce updated 30-m resolution maps of persistent ice and snow cover. In the short term, automated PISC maps can be used to rapidly identify areas where substantial changes in glacier area have occurred since the most recent conventional glacier inventories, highlighting areas where updated inventories are most urgently needed. From a longer term perspective, the automated production of PISC maps represents an important step toward fully automated glacier extent monitoring using Landsat or similar sensors. View Full-Text
Keywords: remote sensing of glaciers; snow and ice; Landsat; arctic remote sensing of glaciers; snow and ice; Landsat; arctic
Figures

Figure 1
