Open AccessArticle
Remote Sens. 2014, 6(9), 8287-8309; doi:10.3390/rs6098287

Detection of Gully-Affected Areas by Applying Object-Based Image Analysis (OBIA) in the Region of Taroudannt, Morocco

1
Department of Geoinformatics-Z_GIS, University of Salzburg, A-5020 Salzburg, Austria
2
Remote Sensing & GIS Research Group, Department of Physical Geography, Goethe University Frankfurt, D-60438 Frankfurt am Main, Germany
*
Author to whom correspondence should be addressed.
Received: 30 April 2014 / Revised: 14 August 2014 / Accepted: 21 August 2014 / Published: 2 September 2014
(This article belongs to the Special Issue Remote Sensing in Geomorphology)
View Full-Text   |   Download PDF [7410 KB, uploaded 2 September 2014]   |

Abstract

This study aims at the detection of gully-affected areas by applying object-based image analysis in the region of Taroudannt, Morocco, which is highly affected by gully erosion while simultaneously representing a major region of agro-industry with a high demand of arable land. As high-resolution optical satellite data are readily available from various sensors and with a much better temporal resolution than 3D terrain data, an area-wide mapping approach to extract gully-affected areas using only optical satellite imagery was developed. The methodology additionally incorporates expert knowledge and freely-available vector data in a cyclic object-based image analysis approach. This connects the two fields of geomorphology and remote sensing. The classification results show the successful implementation of the developed approach and allow conclusions on the current distribution of gullies. The results of the classification were checked against manually delineated reference data incorporating expert knowledge based on several field campaigns in the area, resulting in an overall classification accuracy of 62%. The error of omission accounts for 38% and the error of commission for 16%, respectively. Additionally, a manual assessment was carried out to assess the quality of the applied classification algorithm. The limited error of omission contributes with 23% to the overall error of omission and the limited error of commission contributes with 98% to the overall error of commission. This assessment improves the results and confirms the high quality of the developed approach for area-wide mapping of gully-affected areas in larger regions. In the field of landform mapping, the overall quality of the classification results is often assessed with more than one method to incorporate all aspects adequately. View Full-Text
Keywords: object-based image analysis; gully; landform mapping; gully-affected areas; accuracy; manual assessment; optical satellite data object-based image analysis; gully; landform mapping; gully-affected areas; accuracy; manual assessment; optical satellite data
Figures

This is an open access article distributed under the Creative Commons Attribution License (CC BY 3.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

d'Oleire-Oltmanns, S.; Marzolff, I.; Tiede, D.; Blaschke, T. Detection of Gully-Affected Areas by Applying Object-Based Image Analysis (OBIA) in the Region of Taroudannt, Morocco. Remote Sens. 2014, 6, 8287-8309.
