Open AccessArticle
Remote Sens. 2018, 10(1), 25; doi:10.3390/rs10010025

Evaluation of Accuracy and Practical Applicability of Methods for Measuring Leaf Reflectance and Transmittance Spectra

1
Department of Built Environment, School of Engineering, Aalto University, P.O. Box 14100, FI-00076 Aalto, Finland
2
Department of Electronics and Nanoengineering, School of Electrical Engineering, Aalto University, P.O. Box 15500, FI-00076 Aalto, Finland
3
VTT Technical Research Centre of Finland, P.O. Box 1000, FI-02044 VTT Espoo, Finland
*
Author to whom correspondence should be addressed.
Received: 6 October 2017 / Revised: 13 December 2017 / Accepted: 21 December 2017 / Published: 24 December 2017
(This article belongs to the Special Issue Recent Progress and Developments in Imaging Spectroscopy)
View Full-Text   |   Download PDF [4060 KB, uploaded 24 December 2017]   |

Abstract

Leaf reflectance and transmittance spectra are urgently needed in interpretation of remote sensing data and modeling energy budgets of vegetation. The measurement methods should be fast to operate and preferably portable to enable quick collection of spectral databases and in situ measurements. At the same time, the collected spectra must be comparable across measurement campaigns. We compared three different methods for acquiring leaf reflectance and transmittance spectra. These were a single integrating sphere (ASD RTS-3ZC), a small double integrating sphere (Ocean Optics SpectroClip-TR), and a leaf clip (PP Systems UNI501 Mini Leaf Clip). With all methods, an ASD FieldSpec 4 spectrometer was used to measure white paper and tree leaves. Single and double integrating spheres showed comparable within-method variability in the measurements. Variability with leaf clip was slightly higher. The systematic difference in mean reflectance spectra between single and double integrating spheres was only minor (average relative difference of 1%), whereas a large difference (14%) was observed in transmittance. Reflectance measured with leaf clip was on average 14% higher compared to single integrating sphere. The differences between methods influenced also spectral vegetation indices calculated from the spectra, particularly those that were designed to track small changes in spectra. Measurements with double integrating sphere were four, and with leaf clip six times as fast as with single integrating sphere, if slightly reduced signal level (integration time reduced from optimum) was allowed for the double integrating sphere. Thus, these methods are fast alternatives to a conventional single integrating sphere. However, because the differences between methods depended on the measured target and wavelength, care must be taken when comparing the leaf spectra acquired with different methods. View Full-Text
Keywords: spectroscopy; integrating sphere; leaf clip; contact probe; leaf optical properties; reflectance; transmittance; albedo spectroscopy; integrating sphere; leaf clip; contact probe; leaf optical properties; reflectance; transmittance; albedo
Figures

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Hovi, A.; Forsström, P.; Mõttus, M.; Rautiainen, M. Evaluation of Accuracy and Practical Applicability of Methods for Measuring Leaf Reflectance and Transmittance Spectra. Remote Sens. 2018, 10, 25.
