Open AccessArticle
Energies 2014, 7(3), 1621-1640; doi:10.3390/en7031621

Methods to Increase the Robustness of Finite-Volume Flow Models in Thermodynamic Systems

Thermodynamics Laboratory, University of Liege, Batiment B49, Chemin des Chevreuils 7, 4000 Liège, Belgium
*
Author to whom correspondence should be addressed.
Received: 27 September 2013 / Revised: 7 March 2014 / Accepted: 10 March 2014 / Published: 18 March 2014
View Full-Text   |   Download PDF [409 KB, uploaded 17 March 2015]   |

Abstract

This paper addresses the issues linked to simulation failures during integration in finite-volume flow models, especially those involving a two-phase state. This kind of model is particularly useful when modeling 1D heat exchangers or piping, e.g., in thermodynamic cycles involving a phase change. Issues, such as chattering or stiff systems, can lead to low simulation speed, instabilities and simulation failures. In the particular case of two-phase flow models, they are usually linked to a discontinuity in the density derivative between the liquid and two-phase zones. In this work, several methods to tackle numerical problems are developed, described, implemented and compared. In addition, methods available in the literature are also implemented and compared to the proposed approaches. Results suggest that the robustness of the models can be significantly increased with these different methods, at the price of a small increase of the error in the mass and energy balances. View Full-Text
Keywords: finite volumes; chattering; two-phase flow; stiffness; Modelica finite volumes; chattering; two-phase flow; stiffness; Modelica
This is an open access article distributed under the Creative Commons Attribution License (CC BY 3.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Quoilin, S.; Bell, I.; Desideri, A.; Dewallef, P.; Lemort, V. Methods to Increase the Robustness of Finite-Volume Flow Models in Thermodynamic Systems. Energies 2014, 7, 1621-1640.
